iSP Technologies Tripower 900 Active Series Owner's Manual

Active 3 way speaker system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Please read this very carefully before operating this unit
• Read ALL instructions carefully before using this unit.
• Do not operate this unit near water, in the rain or where there is moisture.
If this warning is ignored a serious electrical shock or death may occur.
• Do not attempt to service this unit. No user serviceable parts inside. Refer
servicing to qualified, ISP approved service personnel.
• Never remove or defeat the ground connection on the power cord of this
unit.
• Care should be taken to avoid spilling any foreign objects or liquid into this
unit.
• This active speaker system has three internal power amplifiers and an
external heatsink located on the back of the speaker for cooling of the
internal amplifiers. Care should be taken to avoid placing this active
speaker in a location where the external heatsink does not allow proper
cooling of the internal amplifiers. Avoid placing this system close to other
heat sources. The external heatsink may reach high temperatures under
normal use. Do not block the external heatsink with any other object.
Make certain there is proper ventilation for the external heatsink when is
use.
• Do not drive the Tripower 900 into excessive heavy distortion for an
extended period of time to avoid premature speaker failure.
• Failure to follow these instructions may void the warranty.
PRECAUTIONS!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tripower 900 Active Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iSP Technologies Tripower 900 Active Series

Summary of Contents for iSP Technologies Tripower 900 Active Series

  • Page 1 PRECAUTIONS! Please read this very carefully before operating this unit • Read ALL instructions carefully before using this unit. • Do not operate this unit near water, in the rain or where there is moisture. If this warning is ignored a serious electrical shock or death may occur. •...
  • Page 2 G-16 when measured on the A scale of a standard sound level meter at slow response. INTRODUCTION Thank you for purchasing ISP Technologies Tripower 900 active speaker system. The Tripower 900 is a high output three-way active speaker system designed to deliver HI-FI sound quality for high SPL sound reinforcement applications.

  • Page 3: Rear Panel Description

    PLACEMENT The Tripower 900 is designed to sit on the floor or stage. Do not position or mount the cabinet where it can tip over and fall on someone. Do not attempt to mount the cabinet on speaker stands. Do not attempt to ‘fly’ (suspend by cables, chains, ropes, etc.) the cabinet. It was not designed for flying.

  • Page 4: Fuse Replacement

    4. BALANCED ¼” PHONE INPUT-This jack provides an input for balanced or unbalanced line level signal source. 5. BALANCED XLR INPUT-This female XLR connector provides an input for balanced line level signal source 6. BALANCED ¼” PHONE OUTPUT – This ¼” phone provides a balanced loop through for connecting to additional powered cabinets.

  • Page 5: Connection Diagram

    CONNECTION DIAGRAM BALANCED CONNECTION DESCRIPTION The ISP Tripower series has balanced XLR and ¼” phone inputs and outputs configured to AES standards (Audio Engineering Society). These connections are connected in a loop through configuration and will accept a balanced line-level input. The standard phase configuration is that pin 2 is (+), pin 3 is (-), and pin 1 is shielded ground on the XLR.

  • Page 6: Thermal Conditions

    THERMAL CONDITIONS The ISP Tripower 900 Series is capable of producing in excess of 900 watts at full power. This generates heat that must be dissipated in order to maintain reliability and insure the amplifier components stay within their operating temperature specs. To accomplish this the amplifier is mounted on a heatsink that is exposed on the rear of the cabinet.

  • Page 7: Specifications

    SPECIFICATIONS System Frequency Range 40Hz - 20KHz Frequency Response (-3dB) 45Hz - 17KHz Horizontal Coverage Angle 90 degrees. Vertical Coverage Angle 40 degrees. Peak Output @ 1m 129 dB Crossover Points 350 Hz, 2.2KHz Input Type Balanced differential Input Impedance 10K ohms Thermal Protection Output Drivers have internal protection, self resetting.

  • Page 8: Warranty And Service

    Any damage resulting from the misuse or the failure to follow the precautions and instructions will void the warranty. In the event that the unit needs to be repaired. Please return the unit to ISP Technologies directly. Simply repack the unit, send a copy of the original receipt, a note stating the...
