- Page 1 AXIS T90B Series AXIS T90B15 W-LED AXIS T90B25 W-LED AXIS T90B35 W-LED AXIS T90B20 IR-LED AXIS T90B30 IR-LED AXIS T90B40 IR-LED Installation Guide...
-
Page 2: Electromagnetic Compatibility (Emc)
Legal Considerations A copy of the original declaration of conformity may be obtained from Axis Communications AB. See Video and audio surveillance can be regulated by Contact Information on page 3 . laws that vary from country to country. Check the... -
Page 3: Photobiological Safety
이 기기는 가정용(B급) 전자파적합기기로서 Should you require any technical assistance, please 주로 가정에서 사용하는 것을 목적으로 하며, contact your Axis reseller. If your questions cannot 모든 지역에서 사용할 수 있습니다. 적절히 be answered immediately, your reseller will forward 접지된 STP (shielded twisted pair) 케이블을... -
Page 5: Hazard Levels
AXIS T90B Series Safety Information Read through this Installation Guide carefully before installing the product. Keep the Installation Guide for future reference. Hazard Levels Indicates a hazardous situation which, if not DANGER avoided, will result in death or serious injury. -
Page 6: Safety Instructions
NO TICE TICE TICE • The Axis product shall be used in compliance with local laws and regulations. • Store the Axis product in a dry and ventilated environment. • Avoid exposing the Axis product to shocks or heavy pressure. -
Page 7: Installation Steps
AXIS T90B Series Installation Guide This Installation Guide provides instructions for installing AXIS T90B Series. Installation Steps Make sure the package contents, tools and other materials necessary for the installation are in order. See page 7 . Study the hardware overview. See page 8 . -
Page 8: Hardware Overview
AXIS T90B Series Hardware Overview Illuminator Photocell Cable Breather gland... - Page 9 AXIS T90B Series Power cable (red) Power cable (black) Photocell cable (white) Photocell cable (yellow) Telemetry cable (purple) Telemetry cable (orange)
- Page 10 AXIS T90B Series Red LED indicator Amber LED indicator Green LED indicator Remote control receiver Mounting bracket (pre-mounted)
- Page 11 AXIS T90B Series AXIS T90B40 IR-LED Cables Mounting bracket (pre-mounted) Bolt Optional Accessories Remote Control For information how to use the remote control, see Access the Product.
- Page 12 Photocell disable button DIM button RESET button STATUS button Disable remote control setup button TELEMETRY button Mounting Brackets To install the product using a compatible bracket from AXIS T90B Mounting Accessories, see the Installation Guide delivered separately with the mounting bracket.
- Page 13 AXIS T90B Series LED Indicators There are three colored LED indicators on the base of the illuminator which provide operating and status information. The color status depends on the current operating mode: • Programming Mode • Normal Operating Mode Programming Mode...
-
Page 14: Specifications
Humidity AXIS T90B Series -50 °C to 50 °C 10–100% RH (con- (-58 °F to 122 °F) densing) Power Consumption Product Value AXIS T90B15 W-LED 12–24 V AC/DC, max 12 W AXIS T90B20 IR-LED 12–24 V AC/DC, max 24 W... -
Page 15: Install The Hardware
For more information about power consumption, see Technical Specifications on page 29 Install the Hardware To install the product using a compatible bracket from AXIS T90B Mounting Accessories, see the Installation Guide delivered separately with the mounting bracket. 1.5 m... - Page 16 AXIS T90B Series CAUTION IR emitted from this product. Avoid prolonged eye exposure or use appropriate shielding or eye protection at distances of less than 1.5 m. Follow these installation procedures: If required, remove the screws and move the standard bracket to the top of the illuminator.
- Page 17 AXIS T90B Series If required, loosen the screws and change to a diverging lens with the desired angle of illumination. The angle of illumination should be adjusted according to the camera field of view to light the whole scene adequately. See Technical...
- Page 18 AXIS T90B Series Screws Diverging lens Note Adjust the vertical position of the illuminator to ensure that the field of view of the camera is illuminated.
- Page 19 AXIS T90B Series Position the illuminator adjacent to the camera and point the illuminator towards the scene. CAUTION Red cable = +ve, Black cable = -ve (polarity sensitive) Mount the power supply. Connect the illuminator to the power supply.
-
Page 20: Access The Product
AXIS T90B Series Illuminator Power cable Power supply Set photocell following output (White & Yellow) Volt free output — normally open (day) to normally closed (night). Connect direct to camera if required to control switchover of day/night cameras. Access the Product... -
Page 21: Normal Operating Mode
AXIS T90B Series • Telemetry TEL enabled • Telemetry input wires soldered together for automatic photocell operation • Telemetry DIM disabled • LED status indicators enabled • Programming Mode Note Changing the settings requires a remote control (optional accessory). The illuminator must be in Programming Mode. -
Page 22: Photocell Sensitivity
AXIS T90B Series Power Adjust The power output of the illuminator can be adjusted between five pre-set levels. Select the required light intensity by using the buttons below. 20% of maximum 40% of maximum 60% of maximum 80% of maximum... -
Page 23: Telemetry Input
AXIS T90B Series There are three pre-defined levels to set the lux level threshold at which the photocell turns the illuminator on or off. Select the required sensitivity level by using the buttons below. Photocell disabled 5 Lux On, 15 Lux Off... - Page 24 AXIS T90B Series Volt-free input: Non polarity sensitive Short circuit = Light on TTL input: Orange = TTL +ve Purple = TTL -ve (GND) 0 V = Light on 3 V = Light off The telemetry input wires (orange and purple) are soldered together when shipped from the factory to simulate a volt-free input so that the illuminator automatically turns on and off via the photocell.
- Page 25 AXIS T90B Series Turn the light on (night) and off (day) automatically via the photocell. This is the standard factory setting, no further action is required. Turn the light on and off from a remote switch or input. Used in conjunction with the Timer Function to turn the light on for a pre-defined period of time.
- Page 26 AXIS T90B Series If you wish to cancel the timer period and have the illuminator operate under standard telemetry conditions, press Timer Disabled. Timer disabled 1 minute 3 minutes 10 minutes 30 minutes TEL button LED Status Indicators This status indicator function can be switched on and off by pressing the STATUS button.
-
Page 27: Factory Default
AXIS T90B Series Factory Default Note To activate this feature the button must be pressed continuously for 4 seconds. This is to avoid the possibility of activating this feature accidentally. Once the illuminator has been programmed, the settings will be stored in a non-volatile (stored) memory. - Page 28 AXIS T90B Series • Basics Check the LED status indicator. See LED Indicators. Check polarity of lamp connection: red = +ve, black = -ve Ensure power is 12-24 V AC or DC Ensure telemetry wires are shorted out or closed contact input (zero volt) is applied Check photocell is working.
-
Page 29: Technical Specifications
Check the remote control battery. Technical Specifications Models AXIS T90B15 W-LED AXIS T90B25 W-LED AXIS T90B35 W-LED AXIS T90B20 IR-LED AXIS T90B30 IR-LED AXIS T90B40 IR-LED Supported cameras IR-LED: All Axis cameras with IR cut filter W-LED: All Axis network cameras... - Page 30 Power Consumption maximum light / 20% of maximum light / Standby mode: AXIS T90B15 W-LED: 12 W / 3 W / 0.15 W AXIS T90B25 W-LED: 24 W / 6 W / 0.15 W AXIS T90B35 W-LED: 48 W / 12 W / 0.15 W AXIS T90B20 IR-LED: 24 W / 6 W / 0.15 W...
- Page 31 35°x10° - 170 m (551 ft) 60°x25° - 112 m (367 ft) 80°x30° - 70 m (230 ft) 120°x50° - 65 m (213 ft)** AXIS T90B15 W-LED 10°x10° - 50 m (164 ft)* 35°x10° - 35 m (115 ft) 60°x25° - 20 m (66 ft) 80°x30°...
- Page 32 AXIS T90B Series 80°x30° - 30 m (98 ft) 120°x50° - 20 m (66 ft)** *No diverging lens **Optional accessory Casing Material: Polycarbonate IR-LED: Black W-LED: White and silver Display and indicators LED indicators Environment Outdoor Mounting Wall Ceiling Column...
-
Page 33: Further Information
The size of the product shall be maximum Dimensions (HxWxL) (WxHxL): AXIS T90B15 W-LED: 75 x 100 x 64 mm (3 x 4 x 2.5 in) AXIS T90B25 W-LED: 100 x 135 x 66 mm (4 x 5 x 2.5 in) AXIS T90B35 W-LED: 135 x 180 x 68,2 mm (5 x 7 x3.2 in) -
Page 34: Warranty Information
AXIS T90B Series Warranty Information For information about Axis’ product warranty and thereto related information, see www.axis.com/warranty/... - Page 36 Installation Guide Ver. M3.2 AXIS T90B Series Date: August 2014 © Axis Communications AB, 2014 Part No. 59159...
