Page 1: Installation Guide
PM4X4A 1080p HDMI Matrix 4X4 With 3D Video, 4 type Matrix mode & RS-232 control Installation Guide WWW.AAVARA.COM AAVARA INNOVATION CORP. ALL RIGHTS RESERVED Rev 1.0... -
Page 2: Table Of Contents
TABLE OF CONTENTS Chapter 1 Introduction........3 1.1 Features ............3 1.2 Technical Specifications......... 4 Chapter 2 Installation......... 5 Chapter 3 Matrix Mode Dip Switch Setting ..6 Chapter 4 RS-232 Command List...... 9 Chapter 5 Troubleshooting ...... -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction Aavara® PM4X4A 4x4 HDMI Matrix supports HDMI v1.4 3D Video Format, uncompressed resolution up to 1080p including multi-channel digital audio signal. Four inputs transmit high definition digital video and audio signals to four displays in selection among. It is compliant with Blu-ray, DVD players, media players and satellite set top boxes to any HDMI compatible display. -
Page 4: Technical Specifications
1.2 Technical Specifications Model No. PM4X4A HDMI Source Input HDMI Single Link, TMDS. Port Display Device Output HDMI Single Link, TMDS. Port Front Bezel: - IR Receiver for IR Remote Control Matrix behavior - 4 Source Input Select Buttons & LED indicator for each HDMI Output... -
Page 5: Chapter 2 Installation
Chapter 2 Installation 1. Plug 5V wall-mounted power supply into the wall outlet. 2. Plug 5V power supply into the HDMI Matrix’s power DC jack. 3. Connect the HDMI cables from the HDMI video source device to the Matrix HDMI Inputs. 4. -
Page 6: Chapter 3 Matrix Mode Dip Switch Setting
Chapter 3 Matrix Mode Dip Switch Setting For multiple outputs selected same source input, PM4X4A provide 4 type Matrix mode dip switch setting for fitting all kind of application/installation requirement. Mode 1 (default, 1 Off, 2 Off) Greatest Common Video resolution & Audio format made sure all displays will show video correctly. - Page 7 Mode 3 (1 Off, 2 On) Follow Output 1 Display, Video Source will handshake with Output 1 Display only and rest of Output displays follow. By using Output 1 Display’s (which installer can sure EDID compatibility) Maximum Video and Audio capability to drive Video Source Device handshaking and output format, for ensuring the video resolution and audio format to all TV/displays/projectors/AV Receiver/AMP at same source input as planned.
- Page 8 Mode 4 (1 On, 2 On) Follow Output 1 Display, and Turn Off Deep Color Output. Which will reserve HDMI bandwidth for high quality multi-channel Audio and improve long distance HDMI transmission stability. Also prevent noise may have when Deep Color enable and low HDMI transmission quality may have (which cause long distance HDMI cable, or HDMI extender applied in installation).
-
Page 9: Chapter 4 Rs-232 Command List
Chapter 4 RS-232 Command List Select Select ASCII Binary Memo Output Source port 00110001 00110010 HDMI Output 1 switch to HDMI ? Input 00110011 00110100 00110101 00110110 HDMI Output 2 switch to HDMI ? Input 00110111 00111000 00111001 01100001 HDMI Output 3 switch to HDMI ? Input 01100010 01100011 01100100... -
Page 10: Chapter 5 Troubleshooting
Make sure all HDMI connectors are tightly secured to all HDMI ports. Turn off all equipments and restart all equipments. HDMI Matrix ※ If the has HDCP compliant issue, please contact your video source device and display/projector seller for HDCP compliant. ALL RIGHTS RESERVED. 2011 AAVARA INNOVATION CORP.
