- Page 1 Information & Operations Manual for Bavaria 32 2011 “Hotel Bravo 32”...
- Page 2 Welcome! Welcome to Horizon Yacht Charters and your Bavaria 32 “Hotel Bravo 32”. We hope you had a pleasant journey and are looking forward to a fantastic holiday and some of the most enjoyable sailing in the world here. This manual is here to guide you through the in’s and out’s of your yacht. Please take the time to read this manual and don’t hesitate to ask any of our professional, friendly staff if you have any...
-
Page 3: Table Of Contents
Contents: Yacht Specifications 12 volt panel and 110 volt breakers Inverter Daily Engine Checks Engine Start Procedures Batteries & Battery Switches Instruments VHF Radio Anchoring, the Windlass, and Picking Up a Mooring Fresh Water System Showers Heads Refrigeration Propane System and Using the Stove The BBQ Air Conditioning Fire Safety... -
Page 4: Yacht Specifications
1. Yacht Specifications Length 32’9” Beam 11’3” Draft 4’11” Fuel 40 gallons Water 40 gallons Engine 27 hp Volvo Penta - Saildrive Location of: Fresh water refill (bow) Diesel refill (starboard aft cockpit) Manual bilge pump (in cockpit) Propane tank (port aft cockpit locker) Windlass breaker (behind port salon seating) Emergency fuel shut-off (Aft, stbd cabin under bunk) Propane shut-off... - Page 5 2. The 12 volt Panel Use the up and down switches (top left) toggle through your water tank gauge, your battery voltages, and your holding tank alarm (alerts at ¾ full). The following functions are controlled by the 12v panel: Top row functions from left to right: Middle row functions from left to right: Navigation Instruments...
-
Page 6: Inverter
110v Breakers 110v breakers: ensure these are on when using 110v outlets (when on shorepower) water heater main breaker: breaker: leave on at all leave this off times The 110v outlets will operate while you are plugged into shore power. Your yacht is equipped with a power inverter that enables you to have 110v power while away from the dock. - Page 7 3. Inverter Your yacht is equipped with a 1500 watt power inverter (12v DC to 110v AC) that allows you to have 110v power when you are not connected to shower power. The inverter is located underneath the charter table and is turned on by a red switch on its face. To avoid additional drain on your batteries while operating electrical appliances off the inverter, the engine should be turned on and idled at 1400 rpm.
-
Page 8: Daily Engine Checks
4. Daily Engine Checks PRIOR TO STARTING ENGINE EACH DAY: Check the oil level using the yellow dipstick located to the left rear of the engine. The level should be at least halfway between the empty and full marks. To add oil, open the black oil filler cap on top of the engine. - Page 9 5. Engine Start Procedures Check the engine every morning before starting as instructed in section 4. Make sure engine is in neutral. Press the ignition switch (allows power to the starter). Press and hold the start button until you hear the engine turn over and begin running, then release the start button. IMMEDIATELY check over starboard side to make sure you have water coming out of the exhaust.
-
Page 10: Instruments
6. Batteries & Battery Switches The systems on your yacht are all 12 volt. The batteries will need to be recharged as often as you deplete them. Conserving power will result in less time needed for charging, so turn off systems that are not actively being used. - Page 11 7. Instruments Your yacht is equipped with the following instruments on board at the helm.: Garmin GMI 10 (windspeed, depth, and more), GHC 10 (auto-helm), and GPS Map 4008. There is also a ship’s compass located at the helm. Use the left and right arrows on the GMI 10 Notice on the GHC 10 display that, just to go through pages of information such as: under the heading numbers, is a bar that...
- Page 12 8. VHF Procedures Your vessel is equipped with an ICOM M412 Marine VHF and is hard-wired to the battery. Push-to-talk Power On/Off and volume control Squelch Channel up/down Familiarize yourself with the VHF controls, particularly switching channels, the volume and squelch knobs, the button for channel 16, and the distress button under the red plastic cover.
- Page 13 Types of Emergency: In the unlikely event that you are involved in an emergency, stay calm and follow these steps. You will also have an Emergency procedure card next to your VHF. Distress: “MAYDAY MAYDAYMAYDAY” – This is an international distress signal and an imperative call for assistance.
- Page 14 9. Anchoring & the Windlass Dropping the Anchor: Preparation: • Establish a non-verbal communication system for signaling between the helmsman at the stern and the fore-deck grunt at the bow, necessary because the noise of wind and the engine will likely make verbal communication difficult and frustrating. Agree upon hand signals to indicate direction-to-go, slowing down, putting engine in neutral, stopping the boat, anchor in the water and clear of the water (to gauge risk of anchor swinging into bow), and anchor free of the bottom.
- Page 15 boat forward 45°angle to the primary. Once in line with the primary, deploy the secondary and allow the elements to push you back. Set the secondary with 1500 rpm astern as with the primary. You may also use the dinghy to drop your second anchor. Retreiving the Anchor: •...
-
Page 16: Picking Up A Mooring Buoy
Picking Up a Mooring Buoy Ensure the dinghy painter is tied off short on the bow or amidships and is clear of the prop. Have a crew member on the bow to pick up the mooring pennant with the boat hook. The bowman should ready a line from each bow cleat to slip through the eye of the mooring pennant. -
Page 17: Fresh Water System
10. Fresh Water System Your yacht has a water capacity of 40 gallons. Use the up/down arrows underneath the LED display on your 12v panel to check the remaining water level. To use the fresh water system, turn on the fresh water breaker button on the 12v panel and open a faucet. -
Page 18: Showers
11. Showers Your yacht has a hot and cold, fresh-water shower in each head and on the transom. If the engine has been running, the hot water can be extremely hot – be careful! In order to use the showers, the fresh-water pump must be activated on the 12v panel. There is also a shower-drain pump switch directly to the right of the fresh-water pump on the 12v panel. - Page 19 12. Heads Nothing is to be put down the head unless it has been digested first. Prior to use, move the lever above the pump handle to the left (wet bowl) and pump 3-5 times to add water. Use the head. Pump 15-20 times on “wet bowl”...
-
Page 20: Refrigeration
13. Refrigeration The system on this boat is an upgraded 12v refrigerator. This system is designed to run 24 hours a day if you wish. To ensure that it does not fail, there are two things you should do: 1. Keep your batteries charged. If the level goes below 12v, the system will malfunction. 2. - Page 21 14. Propane and Stove The propane tank locker is located in the cockpit at the helm seat on the port side. Manual shut-off Valve ON/OFF button in cabinet: -parallel is open -perpindicular is closed Oven latch: push down to open To use: •...
- Page 22 In the event that the alarm goes off, follow these steps: • Close the valve on the propane tank in the cockpit. • Check the stove and surrounding area for the smell of propane and listen for any hissing sound like escaping gas or air. •...
-
Page 23: The Bbq,
15. BBQ • When using the BBQ, tie your dinghy off at the side of the yacht, not off the stern • Never use the BBQ while sailing • Never use the BBQ on a dock • Never change propane tanks when using the BBQ •... - Page 24 16. Fire Safety Prevention is always the best answer to fire safety. Always switch off the propane solenoid when stove is not in use. Never leave the stove, oven, or grill burning unattended. Never change propane tanks while barbecuing. Never smoke below decks. Never smoke when changing propane tanks.
-
Page 25: Air Conditioning
17. Air Conditioning The air conditioning only operates when connected to shore-side power. Once plugged in to shore power, switch on the breakers below the navigation desk. AC circuit breakers Ensure all hatches and companionway doors are closed before starting air conditioning otherwise Power the compressors may freeze up. -
Page 26: Circuit Breakers
Bleeding the System: Sometimes while sailing air will find its way into the water intake and effectively “lock” water from flowing to the units, meaning they cannot run as it is from this circulation of outside water that the units produce cool air. The head units will blink “HPF” (High Pressure Fault) and shut down when an air lock happens. -
Page 27: The Engine
18. The Dinghy and Outboard The driver of the dinghy must be over 18 and must wear the kill cord at all times. Never operate the dinghy under the influence of alcohol or drugs. Always tow the dinghy using a short line while motoring (to prevent fouling the propeller) and a long line while sailing. -
Page 28: Swim Ladder
Swim Ladder Your yacht is equipped with a retractable transom that also doubles as a transom seat when the transom is up. There is a removable swim ladder that is stowed in the port cockpit locker. While underway (sailing or motoring), the transom should remain closed. After you are securely anchored or moored, feel free to deploy the transom for a swim platform or easy access to your dinghy (though be careful not to let the dinghy hull ride up on the platform, which could damage both the dinghy hull and the platform). - Page 29 Glossary: Transit Seacocks and Through-hulls Snubbing line Lee shore Y-valve Pennant line (mooring pennant)
