- Page 1 ProFusion M5 ProFusion M5 ProFusion® M5 U s e r G U i d e...
- Page 3 To reduce the risk of fire, electric shock, or injury: Do not use ProFusion® M5 if it has been exposed to water. Do not use ProFusion M5 if it has been dropped and or damaged. Do not use ProFusion M5 with a damaged power cord.
- Page 4 Agency Listings ProFusion M5 – Version 1.0 This device is in compliance with FCC rules Part 15B for class A devices. This device provides reasonable pro- tection against harmful interference if installed and used in accordance with the instructions.
-
Page 5: Table Of Contents
Contents Features ..............................1 Getting Started Checking Your Package Contents ..........................2 Identifying your ProFusion M5 product version ......................2 Controls and Functions Front Panel .....................................3 Rear Panel....................................4 installation and Setup Placement Guidelines ................................6 Rack Placement ..................................6 Connecting ProFusion M5 ..............................6 Basic operation Powering ProFusion M5 On and Off ..........................8... - Page 6 P r o f u s i o n m 5 u s e r G u i d e...
-
Page 7: Features
ProFusion M5 system Overview Only ProFusion M5 has the adaptability to deliver a variety of multimedia content from a single, space- efficient component. Multiple visual effects can play simultaneously, from Adobe® Flash™ animation to Web content and music videos. -
Page 8: Getting Started
(1) 6’ (183cm) Dual RCA stereo audio cable (1) Stereo male to RCA male Y-cable (Optional) Additional second set of audio cables for ProFusion M5 devices configured for two audio zones Any additional or different cables required to complete the installation will need to be obtained separately. -
Page 9: Controls And Functions
Controls and Functions Front Panel The front panel of ProFusion M5 has an LCD control panel used to change styles and access other aspects of the Control Panel menu system. 1. PoWER Button To turn ProFusion M5 on or off, press the POWER button once. -
Page 10: Rear Panel
Panel The rear panel of ProFusion M5 has a variety of connections that are used to integrate it with your existing audio/visual system and Ethernet network. Version 2.0 Version 1.0 1. Power Cord input ProFusion M5 operates on AC power. - Page 11 This port is designed for the highest resolution video, including “high definition” video. This video out- put type allows for a purely digital video signal from ProFusion M5 to a display or other external video equipment. This connection type is usually found on digital-ready display devices such as certain LCD and plasma displays.
-
Page 12: Installation And Setup
Placement If you are planning on installing your ProFusion M5 in a rack, a minimum 6½” (16.5 cm) (4RU) vertical rack space will be required. Do not improvise a rack mount solution; instead, install your ProFusion M5 on a rack shelf suitable for approximately 40 lbs (18.1 kg) of weight. - Page 13 Note: Although ProFusion M5 version 1.0 has audio jacks located next to the Ethernet port, these outputs have been disabled. sTeP 3 (Optional) If your ProFusion M5 has been configured for two zones of audio, repeat steps 1 and 2 for the second audio zone.
-
Page 14: Basic Operation
Updating ProFusion M5 via disc ProFusion M5 can be updated via Ethernet or disc. It is important to update your ProFusion M5 as soon as you receive any update discs. Please note that if your ProFusion M5 configured for Ethernet updates, you may still receive disc updates, and should load them as soon as they arrive. -
Page 15: Control Panel Menu System
8 Repeat the steps above for any other discs included in your update. Control Panel Menu system ProFusion M5 Control Panel menu system allows you to perform numerous tasks, including: • Changing styles for playback •... -
Page 16: Profusion M5 Device Information
Control Panel Menu Permissions Upon request, your ProFusion M5 Control Panel menu system can be configured so any of the following menu option are disabled: • Changing styles • Changing date and time • Changing volume levels • Disabling and enabling messages for playback •... -
Page 17: Changing Styles
The ability to change styles may be disabled, if requested, for your ProFusion M5. If you attempt to change styles and the control panel displays Access denied: Style change, you do not have permission to change styles. -
Page 18: Viewing And Setting Date And Time
FTP server each time it connects. Viewing date and Time This option allows you to view the current date and time for your ProFusion M5. Changes to the date and time cannot be made from this menu option. -
Page 19: Messaging
Messaging If your ProFusion M5 is configured to utilize Messaging, the playback of messages will be scheduled to play at specific times and days. Changes to Messaging, including scheduling, should be configured by DMX for your ProFusion M5. - Page 20 press the ENTER button. sTeP 4 Press the DOWN button until Messaging Playback is highlighted, then press the ENTER button. Note: If “No Messages” is displayed, there are no messages available for that zone. sTeP 5 Press the UP or DOWN button until the desired message is highlighted, then press the ENTER button. The currently playing content will stop and the message will play.
-
Page 21: Advanced Operation
Press Enter to Reboot. setting the Video Output resolution Your ProFusion M5 will be configured for a specific resolution prior to installation. This resolution will be the DMX Default and can be selected from the Set Resolution menu option. Changing the resolution from the title/artist screen: sTeP 1 Press the ENTER button to access the Control Panel menu system. -
Page 22: Creating A Custom Resolution
M5, the ability to modify and test the current network configuration, and an option to initiate updates. ProFusion M5 utilizes the FTP protocol to connect to its designated server for updates. In order to connect, your firewall will need to allow FTP traffic from your ProFusion M5 to its designated update server. -
Page 23: Viewing The Network Settings
Viewing the Network settings The View Settings option displays the current network configuration for your ProFusion M5. This includes the IP type (DHCP or static), IP address, subnet mask, default gateway, and the IP address of the FTP server your ProFusion M5 will connect to for updates. -
Page 24: Changing The Ip Address And Subnet Mask
it is highly recommended that a connectivity test is performed after changing any network settings. see Testing Your Network Settings (p. 19) for instructions. Changing the iP Address and subnet Mask Changing the IP address and subnet mask from the title/artist screen: sTeP 1 Press the ENTER button to access the Control Panel menu system. -
Page 25: Changing The Ftp Server Ip Address
Testing the Network settings The Test Network Connect option allows you to verify your ProFusion M5 is properly connected to your net- work, and its network settings are correct. This will allow your ProFusion M5 to successfully connect at its designated time. -
Page 26: Updating The Configuration
Note: If new content is available for download, your ProFusion M5 may be updating for a long period of time. It is advisable to check with your network administrator before selecting this option. -
Page 27: System Diagnostics
Connection Idle. system diagnostics The System Diagnostics option, used for troubleshooting, can only be accessed with the assistance of a DMX Custom Service agent. -
Page 28: Appendix A: Glossary
Information displayed on the main screen of the Control Panel menu system for each available zone during music playback, regarding the content currently playing. Zone: ProFusion M5 has one visual zone and up to two music zones that allow for unique music types for dif- ferent areas of a business. -
Page 29: Appendix B: Troubleshooting
This section provides a basic troubleshooting guide for the most common issues. If this list does not help you re- solve your issue, or if you have an issue that is not listed below, please contact DMX Customer Service (see p. 27) for assistance. - Page 30 M5. If the Device ID on the disc matches the Device ID of your Control panel displays Wrong Device ID 10, 27 ProFusion M5 and the update continues to produce the Wrong Device ID error message, contact DMX Customer Service. Verify you are loading the most recent update. The disc will have the —...
-
Page 31: Appendix C: Control Panel Menu System Tree
<Style 2> Back Set Date and time <Resolution 1> Set Date and Time <Resolution 2> View Date and Time DMX Default Device information Custom Back Set Rotation Device ID / Conf Ver / SW Ver / OS Ver Back Style Version info... -
Page 32: Appendix D: Specifications
Appendix d: specifications Video specifications Maximum Resolution: 2560x1600 Screen Refresh Rate: 60 Hertz Broadcast Signals: NTSC M, PAL A Ports Video: 15-pin High-Density D-Sub (VGA) DVI-I TV – 4-pin mini-DIN (S-Video/Composite) audio: 1/8” stereo mini-plug Power specifications (Version 1.0) (Version 2.0) Voltage Mains: 115/230 VAC 115/230 VAC... -
Page 33: Appendix E: Contact Dmx
The Device ID for your ProFusion M5 (see p. 10) • The serial number for your ProFusion M5 (located on the front and rear panels) Note: The serial number for ProFusion M5 version 1.0 is on the rear panel only • Your DMX Account Number... - Page 34 Notes: P r o f u s i o n m 5 u s e r G u i d e...
