- Page 1 Owner’s Manual Evolution Series 820S Power Supply...
-
Page 3: Important Safety Instructions
820S Power Supply Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 4 To prevent shock hazard, all three connections must ALWAYS be used. Connect the MOON 820S only to an AC source of the proper voltage; Both the shipping box and rear panel serial number label will indicate the correct voltage. Use of any other voltage will likely damage the unit and void the warranty AC extension cords are NOT recommended for use with this product.
-
Page 5: Table Of Contents
Table of Contents Introduction ............ 6 Unpacking............7 Installation & Placement ........7 Rear Panel Connections ........8 Connecting the 820S ........8 Operating the 820S ........10 Troubleshooting ..........10 Specifications ..........11 www.simaudio.com Simaudio Ltd., 1345 Newton Road... -
Page 6: Introduction
Your MOON 820S Power Supply incorporates many significant design features to achieve its “world-class” level of performance. This is an abbreviated list of the more important features: Two custom proprietary toroidal transformers with opposed to a single voltage regulation chip. -
Page 7: Unpacking
820S from any potential damage during packaging, storing it in a safe, dry place in case transit. Please write the serial number of your new MOON 820S in the space provided below for future reference. Serial No.: ________________ Installation & Placement... -
Page 8: Rear Panel Connections
610LP Phono Preamplifier (bottom) between one of the 5-pin XLR outputs labeled connected to the 820S with only a 4-Pin XLR cable. “Output 2” on the rear panel of the 820S and the corresponding 5-Pin XLR input on your... - Page 9 Figure 2: Connecting the 820S to other MOON Evolution components IMPORTANT ! Any component(s) connected to the 820S Power Supply will NOT power up, remotely or via their standby button, when the 820S is powered off or in standby. ____________________________________________________________________________________...
-
Page 10: Operating The 820S
820S Power Supply Operating the 820S We recommend leaving your 820S powered up at all times to maintain optimal performance. When you plan on being away for a few days, it may not be a bad idea to power off your 820S. -
Page 11: Specifications
820S Power Supply Specifications Transformers ..........2 x 0.25kVA Total Capacitance .......... 80,000µF Total Inductance ........... 80mH Output Voltage (analog supply output 1) ... ±20 Volts Output Voltage (digital supply output 2).... +14 Volts Power Consumption @ idle ......25 Watts AC Power Requirements .........
