  • Page 1 Owner’s Manual MOON Series 320 S Power Supply...

  • Page 2: Important Safety Instructions

    MOON 320S Power Supply Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 3 To prevent shock hazard, all three connections must ALWAYS be used. Connect the MOON 320S only to an AC source of the proper voltage; Both the shipping box and rear panel serial number label will indicate the correct voltage. Use of any other voltage will likely damage the unit and void the warranty.

  • Page 4: Table Of Contents

    MOON 320S Power Supply Table of Contents Congratulations ..........5 Unpacking and Warnings ........5 Introduction ............ 6 Installation & Placement ........6 310LP Internal Settings ........7 Rear Panel Connections ........8 Operating the 320S .......... 9 Specifications ..........10 www.simaudio.com...

  • Page 5: Congratulations

    Refer to page 7 of this manual for instructions. We hope you enjoy using the MOON 320S Power Supply as much as the pride we have taken in creating this fine audio product. We understand the power and emotion of music and build our products with the goal of faithfully capturing these elusive qualities.

  • Page 6: Introduction

    Installation & Placement The MOON 320S has been designed to be placed side-by-side with the MOON 310LP. Together, these 2 components will fit easily on any standard audio equipment shelving system. As well, feel free to experiment with other placement options for the best possible setup that meets your needs.

  • Page 7: 310Lp Internal Settings

    (4) jumper sockets labeled STR1, STR2, STR3 and STR4. The factory default position for the 2 jumpers is in sockets STR2 and STR4 (positions B in figure 1). To properly operate the MOON 310LP in conjunction with the MOON 320S, you will need to move these 2 jumpers into sockets STR1 and STR3 (positions A in figure 1).

  • Page 8: Rear Panel Connections

    Figure 3: MOON 320S Rear panel The rear panel of the MOON 320S will look similar to Figure 3 (above right). There is a 4-pin female XLR connector, labeled “DC output”, located on the left side. On the right side are the the power “main switch” and IEC receptacle, labeled “AC Input”.

  • Page 9: Operating The 320S

    We recommend that you leave your MOON 320S Power Supply powered up at all times to maintain optimal sonic performance. In the event that you plan to be away from your home for a few days, powering off the MOON 320S may not be a bad idea.

  • Page 10: Specifications

    Signal-to-Noise Ratio (full scale @ 66dB gain) ..92dBr Note: All other MOON 310LP specifications remain unchanged when using it in conjunction with the MOON 320S. Fuse Replacement: For the 120V version use a 0.2A slow blow (5 x 20mm size).
