  • Page 1 Sat Series Active Monitor Series Sat 5 & Sāt 10S...
  • Page 2 Signal to Noise Ratio & Total Harmonic Distortion. Sāt in Sanskrit means ‘the absolute truth’! In the same essence the Studiomaster Professional Sāt Series is designed to reveal absolute truth of your mixes! 2.
  • Page 3 1. Power Input: Connect the supplied power cord to the unit & make sure the right power is being supplied. As an additional safety measure please use a stabilizer like the Studiomaster Professional SVC series, to protect the product from spikes & surges.
  • Page 4 Adjustment range is from -30dB to + 6dB ( ) & -80dB to + 6dB ( ), which should suffice for Sat 5 Sāt 10S most conditions. 5. HF Adjustment: This knob is used to control the high frequency adjustment of this speaker. Room acoustics may dictate which type of adjustment you need to make to retain a flat frequency response from the monitor.

  • Page 5: Setup Diagrams

    4. Setup Diagrams Without Subwoofer: PLAY BACK / RECORD PHONES AiR 4 LINE LINE LINE LINE MONO MONO 60db 60db 60db 60db GAIN GAIN GAIN GAIN LINE 3/4 LINE 5/6 MAIN PEAK PEAK PEAK PEAK POWER PORER Phantom - 11 GAIN GAIN POWER...

  • Page 6: Speaker Placement

    5. Speaker Placement Positioning your monitors correctly in the studio is critical to their performance. Typically, they should be placed so that the listening position is fully “covered” with all monitors resting on the same horizontal plane. A great way to test a monitor for its imaging capability is to play back a CD or DVD recorded acoustically in stereo (or one recorded in surround sound if you have a surround sound set up).
  • Page 7 6. SPL Curves Sāt 5 Sāt 10S...

  • Page 8: Specifications

    38.2 x 35.5 x 39.8 Net Weight 7.2Kg 17Kg FUSE Rating (5mm x 20mm) 220V - 240V 0.8A Other recommended products from Studiomaster Professional: For Studio: • SM 900C - High Quality Condenser Microphone. • Phantom 11 - External Phantom Power Supply Unit. •...
