GMSK-modulated or 8-PSK-modulated signal to RF. [Fig. 3.1] Block diagram of RF part A generic, high-level functional block diagram of KT610 is shown in Figure 3-1. One antenna collects base station forward link signals and radiates handset reverse link signals. The antenna connects with receive and transmit paths through a SKY77519(EDGE PAM+ASM).
2. The amplitude-modulated (AM) component is applied to the ramping control pin of Polar power amplifier from a DAC within the MSM KT610 power supply voltages are managed and regulated by the PM6658 Power Management IC. This versatile device integrates all wireless handset power management, general housekeeping, and user interface support functions into a single mixed signal IC.
The antenna switch module allows multiple operating bands and modes to share the same antenna. In KT610, a common antenna connects to one of six paths: 1) UMTS-2100 Rx/Tx, 2) GSM-900 Rx, 3) GSM-900 Tx, 4) GSM- 1800 Rx, and 5) GSM-1800, GSM-1900 Tx(High Band Tx’s share the same path), 6) GSM-1900 Rx.
3.10.1 Keypad KS10 has 75 buttons, 19 keys in Folder, 54 keys in main and 2 side keys. KT610 use key coder IC because Stn8810 has not enough GPIO. Key coder IC use interrupt and I2C interface for communication with STn8810.
The USB 2.0 specification requires hosts such as PCs to support all three USB speeds, namely low- speed (1.5 Mbps), full-speed (12 Mbps) and hi-speed (480 Mbps). The USB 2.0 specification allows peripherals to support any one or more of these speeds. KT610’s USB interface uses the PM6658 internal logic for USB Transceiver. Name Note...
3. TECHNICAL BRIEF 3.15 Camera interface KT610 has two cameras : 2M Pixel CMOS and VGA Pixel CMOS Camera Below figures shows the camera board to board connector and camera I/F signal. 3.15.1 2 Mega Camera Interface Figure. Schematic of 2 Mega Camera EMI/ESD filter I/F Figure.
3. TECHNICAL BRIEF 3.16 Bluetooth KT610 supported bluetooth, which is possible to data file transfer, BT headset call. CPU (STn8810) interfaces with bluetooth one chip module (U100 in Sub) which includes RF and baseband. The STLC2500C is a single chip ROM-based Bluetooth solution for applications requiring integration up to HCI level.
2M camera control signals are generated by STN8810 and MSM6280. VGA camera control signals are generated by STN8810. Data signals are processed by STN8810. KT610 has two cameras. The one is a 2 Mega Camera, the other is VGA camera. 2M START Check the camera conn.
Page 151
MMI18P-COMM (MRO 1671570) 5.5.4 Com Port Setting method about USB • KT610 Model USB Driver is just same as KT610 Model which is not working as normal Qualcomm 3G chipset. • After connecting USB1, USB2, etc. to Phone, • f you find new HW device in Device Manager and click Folder which contains above file ‘lgjoyusb.sys’, then it will be installed.
• Port Selection : After checking the USB Mode , it should be checked for the download port from COM57 to COM72. • DLL Selection : Selecting the DLL file in C:\DOWNLOAD\Model\KT610 • Run Download Configuration : - AP Image : Select the BIN file in C:\DOWNLOAD\Model\KT610 - MP Image : Select the DZ file in C:\DOWNLOAD\Model\KT610 - Select the Update Boot, Update Modem Boot when changing the buyer.
