TECHNICAL DATA / REFERENCE
Toning Black-and-White Materials
Photographic print toners are chemical solutions used to treat
black-and-white prints after processing. What does
treatment with a toner solution do to a black-and-white
print?
• Changes or enhances the image color to convey a
mood or impression, from subtle to extraordinary.
• Extends the life of the print image during display or
storage. Toning converts the black-and-white silver
image to an inert compound, which reduces the harmful
effects of intense light, ultraviolet radiation, oxidizing
gases, extremes of temperature and humidity, and
fumes. All Kodak toners will protect the image whether
or not they produce a color shift.
• Enhances the maximum density (D-max) in the
image. With some toners, you can increase the shadow
densities in prints with little or no change in the image
tone. For example, you can treat KODAK
PROFESSIONAL POLYMAX Fine-Art Paper
(discontinued) in KODAK PROFESSIONAL Rapid
Selenium Toner to produce a richer range of tones in the
shadow areas. The curve below shows the increase in
upper-scale contrast and D-max of KODAK
PROFESSIONAL POLYMAX Fine-Art Paper toned in
Rapid Selenium Toner (diluted 1:40).
3.0
KODAK PROFESSIONAL POLYMAX Fine-Art Paper
KODAK PROFESSIONAL DEKTOL Developer (1:2).
20 C (68 F) for 2 minutes
treated in KODAK PROFESSIONAL
Rapid Selenium Toner (1:40)
2.0
for 4 minutes
1.0
0.0
1.0
0.0
LOG EXPOSURE (lux-seconds)
F002_1087AC
©Eastman Kodak Company, 2006
Toned
Untoned
1.0
2.0
SELECTING A KODAK PROFESSIONAL
PACKAGED TONER
The visual effect of a toner depends on a combination of
factors:
• the toner and toner dilution
• the paper emulsion type, surface, and stock tint
• the length of the toner treatment
• the processing of the paper
Not all toners perform the same way with all papers. Be
sure to select a compatible paper/toner combination. See the
tables Tones Produced by Paper/Toner Combinations and
Degree of Toning Produced by Paper/Toner Combinations.
KODAK Packaged Toners
KODAK PROFESSIONAL Rapid Selenium Toner.
Produces several cool chocolate-brown hues with warm-tone
papers, purplish brown tones with neutral-tone papers, and
very little or no change with cold-tone papers. Use the 1:20
dilution for print protection. To increase shadow contrast
and maximum density with a minimum tone change, use a
1:20 or 1:40 dilution. You can also use this toner with
black-and-white films. It converts the silver image to silver
selenide.
KODAK PROFESSIONAL Brown Toner.
variety of brown tones on neutral- and warm-tone papers.
You can also use it to treat black-and-white negatives and
slides for long-term keeping. It converts the silver image to
silver sulfide.
KODAK PROFESSIONAL Sepia II Warm Toner.
Produces noticeably warmer brown tones on most
black-and-white papers than KODAK Sepia Toner. It
includes a bleach and a redeveloper. It converts the silver
image to silver sulfide.
KODAK PROFESSIONAL Sepia Toner.
brown tones on cold-tone papers or yellowish brown tones
on warm-tone papers. It includes a bleach and a redeveloper.
It converts the silver image to silver sulfide.
May 2006 G-23
Produces a
Produces warm
