Summary of Contents for Abee V11
-
Page 2: Table Of Contents
Menu Product Features ............1 Notes ................2 Product Appearance ..........3 Hardware Installation Guideline ....... 4 Operational Guideline ..........6 i. Turn on / Turn off ..................6 ii. Recording ....................6 iii. Emergency Recording ................7 iv. Video playback/Locked file/Unlock/Delete ..........8 v. -
Page 3: Product Features
V11 Car Recorder Manual Product Features 產品特色 ● High-definition video recording in HD 720P @ 30fps ● Auto loop recording with No Interval Time File Saving Technology to record every second ● Emergency record function to protect important incidents. ● Low-light CMOS HD Sensor for better night vision ●... -
Page 4: Notes
2. Please format the memory card with V11 before use 3. Please use Abee V11 original car charger and accessories. 4. When your engine is off, it is recommended to unplug the cigarette charger and Abee V11 to prevent unnecessary draining of your car battery. -
Page 5: Product Appearance
V11 Car Recorder Manual Product Appearance 產品外觀示意圖 ○ ○ 1 On/Off Key 8 Bracket slot ○ ○ 2 Menu/Exit Key 9 Memory card slot（Micro SD） ○ ○ 3 Up/Play/Delete Key 10 Mini USB port ○ ○ 4 Down/Stop/Lock 、Unlock 11 RESET ○... -
Page 6: Hardware Installation Guideline
V11 Car Recorder Manual Hardware Installation Guideline 硬體安裝指南 Installation Connect the device with the bracket by inserting the screw hole on top of your device in the screw of the bracket; turn the screw knob clockwise until firmly installed. Place your Car Camera Recorder in the... - Page 7 Clean the bracket suction plate before installation. ※ Warning Do not install Abee products over an air bag cover or within the air bag deployment zone. The company assumes no responsibility of liability for injury or death as a result of...
-
Page 8: Operational Guideline
V11 Car Recorder Manual Operational Guideline 使用說明 Turn on / Turn off Turn on ： When the device is not connected to external power, press ON/OFF key and hold for 2 seconds to turn on the device. Turn off ：... -
Page 9: Emergency Recording
V11 Car Recorder Manual iii. Emergency Recording Under the recording mode press key for Lock. T he device will automatically lock the file. A “Lock” icon will be shown on the upper right corner of the screen immediately and the file will not be deleted by loop recording. -
Page 10: Video Playback/Locked File/Unlock/Delete
V11 Car Recorder Manual Video playback/Locked file/Unlock/Delete Vide preview ： Under general mode, press key to choose Play, to enter the video playback menu, key to select the file type Normal Records or Locked Records ， Press key to choose OK, after choosing the type of video, and you will see the videos playlist. - Page 11 V11 Car Recorder Manual to choose Delete, the screen will show the confirmation message, use to choose YES or NO, then press key to choose OK, to delete file. Press key to choose Back, to return to the pause screen. Press key to choose Resume to playback.
-
Page 12: Menu Function
V11 Car Recorder Manual Menu function In general mode, press the key and choose Menu, to enter the menu screen. Time Setup Set up the current time In the menu screen: Select key to set up the date Time Setup. -
Page 13: Memory Card (Micro Sd) Pc Connection Instruction
Remove the memory card after turning off the device. Insert the memory card in a PC card reader. Your PC will detect a removable device. Open Windows Explorer to browse the files on the V11 memory card. Memory card content operational, please refer to the next section, ADR player software operational. - Page 14 V11 Car Recorder Manual screen RAM: At least 1 GB of memory OS: Required to support Windows XP 、 Windows Vista(32 bit & 64bit) & Windows 7 (32 bit& 64bit) Audio: System must have the audio device installed ...
- Page 15 V11 Car Recorder Manual Software interface description A. Image display area: Displays the current playback image. B. G-Sensor display: Show G-sensor information of current video. C. Playback progress bar: Shows the progress of video playback, you can drag the mouse to the video position where you want to see.
- Page 16 V11 Car Recorder Manual Operational guideline: Buttons instructions Open disk: Open the video in which SD card drive Snapshot button: Save the current screen captured into a JPG image file. During playback or pause playback of the video, you can press this button to save as a image file, file name will be saved to screen name at the time.
- Page 17 V11 Car Recorder Manual b. If you want to save more than one group of films shown in the video group list, check the groups you want to save (see below), then click save button, these groups were transferred directly saved as AVI File. If the video a long time, transfer process may take some time, please be patient and you may press stop button to cancel during transfer processing.
- Page 18 V11 Car Recorder Manual Delete video button: Delete recorded video in the Micro SD card. a. Remove certain videos within a single section of the group: Selected in the group to the group list, click Delete button will appear as below, then choose to...
- Page 19 (as picture below) a. Format Micro SD card Will format the Micro SD card reader into the Abee V11 proprietary file format, and then of ADR Player software will be copied in to the memory card so you can use any computer to watch the video ※...
- Page 20 Micro SD speed test Test currently used Micro SD card read and write speed, for the smooth of Abee V11 HD video, the speed test from the Micro SD card write speed should be at least 4000KB/sec.
- Page 21 V11 Car Recorder Manual the video is under slow down speed, it can be adjusted quickly. Play back volume: adjust play back volume. Unlock button: to unlock the protected video for the video list displayed in the group that been protected, press this button will pop up a whether determine to unlock the video message, press “yes”...
- Page 22 V11 Car Recorder Manual G-Sensor information display switch: the G-Sensor information display area can be turned on or off. Press to open or close the G-Sensor information display area, the G-Sensor X, Y, and Z axes of information available to be the accident reference.
-
Page 23: Specifications
V11 Car Recorder Manual 主要規格 Specifications Display 2.4” TFT LCD color screen Image sensor CMOS HD Sensor Lens 140° wide angle lens Video Resolution HD 1280×720 (30fps) Video Format Video Compression MJPEG Auto loop recording with no Interval Time File Saving... - Page 24 V11 Car Recorder Manual 快譯通股份有限公司 INSTANT TECHNOLOGY CO., LTD. 地址：114 台北市內湖區瑞光路 316 巷 3 號 1 樓 Add: 1F., No.3, Lane 316, Rueiguang Rd., Neihu District, Taipei 114, Taiwan, R.O.C. 台北：(02)8752-5008 台中：(04)2472-6552 高雄：(07)536-5989 網址：http://www.instant.com.tw 客服專線：(02)8752-5007...
