D-Link DAS-3216 Quick Installation Manual

Adsl ip dslam multiplexer.
Hide thumbs


Advertisement

This product can be set up using
any current web browser, i.e.,
Internet Explorer 6.x, Netscape
Navigator 7. x.
Before You Begin
This Quick Installation Guide gives step-by-step instructions for setting up the D-Link
DAS-3216/3208 ADSL IP DSLAM. This Quick Installation Guide only introduces you for the
main setup procedure. For more detailed information about complete installation and
configuration, please refer to the User's Manual on master CD included with your DLSAM.
Check Your Package Contents
If any of the above items are missing, please contact your reseller
©2004 D-Link Corporation, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice. D-Link ADSL IP DSLAM.
• D-Link DAS-3216/3208 ADSL IP DSLAM
• CD-ROM (containing Manual and Warranty)
•Ethernet Cable (CAT5 UTP Straight-Through)
• AC Power Cord (AC power module only)
• RS-232 cable
DAS-3216/3208
ADSL IP DSLAM
Using a power
supply with a
different voltage rating
will damage and void
the warranty for this
product.
