9-5. INLET VALVE ASSEMBLY

Wiring
diagram
Depending on the cycle and water temperature, the controller will energize the hot or cold
Function
water valve solenoids to meet the selected water temperature.
Test After pull out the connector of defective valve, check the resistance.
points
and
Result
Circuit in the MAIN PWB
MICOM
Inlet valve driving circuit
Wiring Diagram
1 2 3 4
1 2 3 4
WH
NA
WASH
(1) (2)
(1) (2)
Rg
IC
MIAN PWB
BL3
NA4 3 2 1
1
3 2 1
1
COMMON
GY YL
(BK)
BL BL
1 2 1 2
MAIN PRE
WASH
INLET VALVE
* Each circuits of loads in wiring diagram are all same.
(1) (2)
41
Vdc
Cg
Rs
Cs
PCB
CONNECTOR
INLET
VALVE
BL4
2 3 4
2 3 4
BL
2 RD
1 2 1
HOT
BLEACH
VALVE
Test points
(1) (2)
Result
Vac
(1)-(2)
0.8-1.2 kΩ
