  • Page 1 Ref. 554912 User Manual DVB-T SD/HD Encoder/Modulator w w w . t e l e v e s . c o m...

  • Page 3: Table Of Contents

    Index Introduction ..............General description .

  • Page 4: Introduction

    1.1 General Description Bit rate 1.000~19.000 Mbps Interface HDMI or Stereo/Mono (RCAs) 554912 encoder & modulator (home use) is Televes´ consumer product which Audio Sample rate 48KHz allows audio/video signal input in TV distributions with applications in home Bit rate 64, 96, 128, 192, 256, 320, 384kbps entertainment, surveillance control, inns, restaurants, small shops, etc.

  • Page 5: Product Description

    2. Product description 2.1 Indicators and controls Power/alarm/lock LCD display indicators (PVR/Playback/Upgrade) JTAG port Control Buttons for upgrade DC 12V HDMI RF In RF Out YPbPr/S-Video/AV Grounding DC 12V Power input HDMI HDMI input (supporting SD and HD signals) YPbPr/S-Video/AV YPbPr/S-Video/AV signal input through a VGA adapter cable USB Port Video Record, Playback and upgrade SW...

  • Page 6: Installation/Application

    3.1 Button introduction space around from each other once the devices have been installed. 554912 Encoder Modulator is controlled and managed through the key board Please connect the cable(s) from the source. The signal source can be from a and LCD display.

  • Page 7: Management

    3.2 Management Switch On, then below status will be displayed, few seconds’ initialization then open startup picture.

  • Page 8: General Setting For Main Menu

    Televes recommends the use of high quality USB devices. power on. (*) Televes does not guarantee 100% compatibility with all USB devices. 4 Video Parameters: In the “Interface” option you can select the input signal that will use (HDMI, YPbPr, CVBS or S-Video). User can also adjust values of rest items.
  • Page 9 At this moment (recording or playing TS fi les), the keys has other functions: 25 Save Confi g: Yes/No-to save/give up the adjustment of setting. Play/Pause Back Main Menu 26 Load Saved CFG: Yes/No-to load/ not to load the saved confi guration. 27 Factory Reset: Yes/No-choose/not choose the factory’s default confi guration.

  • Page 10: Ts Creator Software

    Users can fi lter the null packet to boost Click to add audios the video´s eff ect bit rate. A single video can be maximum 2.0 GB in size. (554912 cannot play bigger than 2GB) Click to set a save path for the TS video to be created.

  • Page 11: File Management

    Rename the fi les before creating a new video to avoid covering the previous fi les. If you rename “FinalOutput-204-0.ts” or “FinalOutput-204-0.tsinfo”, always keep the names the same (Extension excluded) and then 554912 can read them and play the video.
  • Page 12 DVB-T SD/HD Encoder/Modulator...
  • Page 14 DVB-T SD/HD Encoder/Modulator...
  • Page 16 554912_001_EN...
