Aiwa XP-V410 Service Manual

SERVICE MANUAL
COMPACT DISC PLAYER
MODEL CODE : 86HR8-0117(B)
• This model has two types of CD mechanism, DA23L and DA23LN,
and they are not compatible.
• Note : For model using DA23LN CD mechanism specifications
label indication is different. Refer to illustration on page 2.
If requiring the other information, see Service Manual of the XP-V410 (TYPE:Y1,YJ1)/
XP-V411(TYPE:AEZ1,AHRJ1)/XP-V412 (TYPE:AK1,AEZ1,AEZ1B)(S/M Code No. 09-003-342-6R1).
XP-V410 (TYPE:YJ)/XP-V411(TYPE:AHR,AHC,AHA,ALH)/XP-V416 (TYPE:ALH)
(S/M Code No. 09-003-342-6N1).
XP-V412 (TYPE:AEZ1)(S/M Code No. 09-003-342-6S1)
XP-V416 (TYPE:AHAB)(S/M Code No. 09-003-342-6N2).
XP-V410
XP-V411
XP-V412
XP-V416C
BASIC CD MECHANISM : DA-23LN
S/M Code No. 09-003-342-6S2
Y1(S)YJ1(LT) YJ(S)
AEZ1(L,S) AHR(LL)
AHA(S)ALH(S)
AHRJ1(S,LT) AHC(S)
AK1(S) AEZ1B(S,G)
AEZ1(S,L)
ALH(S) AHAB(S)
