Aiwa XP-V522 Service Manual

Compact disc player
Hide thumbs Also See for XP-V522:
Table of Contents

Advertisement

Quick Links

Download this manual
SIMPLE-2
SERVICE MANUAL
COMPACT DISC PLAYER
• This Service Manual contains information about the difference between
XP-V522 / V523 / V524<AEZ,AHR> and XP-V522<AEZ>.
If requiring other information, see Service Manual of XP-V520 / V521 / V522 /
V523 / V5210 / V5260C<Y,AEZ,AK,ALH,AU>,(S/M Code No. 09-012-441-2R1).
XP-V522
XP-V523
XP-V524
BASIC CD MECHANISM: DA23LH
A par t of contents is adequate.
Re-issuing is under r equest.
S/M Code No. 09-017-441-2S3
AEZ
AHR
AHR

Advertisement

Table of Contents
loading

Related Manuals for Aiwa XP-V522

Summary of Contents for Aiwa XP-V522

  • Page 1 Re-issuing is under r equest. • This Service Manual contains information about the difference between XP-V522 / V523 / V524<AEZ,AHR> and XP-V522<AEZ>. If requiring other information, see Service Manual of XP-V520 / V521 / V522 / V523 / V5210 / V5260C<Y,AEZ,AK,ALH,AU>,(S/M Code No. 09-012-441-2R1).

  • Page 2: Specifications

    SPECIFICATIONS Tracking system: 3-beam laser Supplied headphones HP-M062 <522AEZ> Laser pickup: Semiconductor laser Type: In-ear type D/A conversion: 4-times oversampling digital filter + 1-bit DAC Impedance: 16 ohms Frequency response: 20 - 20,000 Hz Sensitivity: 103 dB/mW Output: PHONES / LINE OUT jack (stereo mini-jack) 524AHR: Recommended commercially available headphones <522AEZ>...

  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C414 87-012-188-080 C-CAP,U 47P-50 J CH<524AHR> C415 87-010-831-080 C-CAP,U,0.1-16F 87-A21-448-040 C-IC,BH6554FV C417 87-012-188-080 C-CAP,U 47P-50 CH 8B-HC4-610-010 C-IC,MN101C439-AJ<522AEZ> C418 87-012-184-080 C-CAP,U 33P-50 CH 8B-HC4-611-010 C-IC,MN101C439-AM<523AHR,524AHR>...
  • Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION S303 87-A91-457-280 C-SW,SL 1-1-3 SS-350-A13B-C-T VR701 87-A92-142-010 C-VR,RTRY30KCX2 H K142R0Z0J X401 87-A70-202-080 C-VIB,CER 16.93MHZ CSACV-MXJ04 *NOTE: EXP= EXCEPT CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm)
  • Page 5 WIRING – 1 (MAIN) <1 / 2> : 522AEZ, 523AHR – 5 –...
  • Page 6 WIRING – 1 (MAIN) <2 / 2> : 522AEZ, 523AHR – 6 –...
  • Page 7 SCHEMATIC DIAGRAM – 1 (MAIN) <522AEZ,523AHR> – 7 –...
  • Page 8 WIRING – 2 (MAIN) <1 / 2> : 524AHR – 8 –...
  • Page 9 WIRING – 2 (MAIN) <2 / 2> : 524AHR – 9 –...
  • Page 10 SCHEMATIC DIAGRAM – 2 (MAIN) <524AHR> – 10 –...

  • Page 11: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 <522AEZ,523AHR> PLATE,LCD DA23LH – 11 –...

  • Page 12: Mechanical Parts List

    MECHANICAL PARTS LIST 1 / 1 <522AEZ,523AHR> REF. NO. PART NO. KANRI DESCRIPTION 8B-HC5-007-010 PANEL,DISPLAY 8B-HC5-017-010 WINDOW,DISPLAY 522<V522AEZ1BF> 8B-HC5-018-010 WINDOW,DISPLAY 523<V523AHRJ1LLF> 8B-HC5-009-010 KEY,PLAY 8B-HC5-052-010 LID,CD (B)<V522AEZ1BF> 8B-HC5-015-010 LID,CD (LL)<V523AHRJ1LLF> 8A-HC5-202-010 JOINT,LCD AHC5 8B-HC5-008-010 HLDR,LID CD 8B-HC5-011-110 KEY,MODE 8B-HC5-010-010 KEY,SKIP 8B-HC4-203-010 SPR-T,OPEN 8B-HC4-002-110 CABI,CENTER<V522AEZ1BF>...
  • Page 13 MECHANICAL EXPLODED VIEW 1 / 1 <524AHR> – 13 –...
  • Page 14 MECHANICAL PARTS LIST 1 / 1 <524AHR> REF. NO. PART NO. KANRI DESCRIPTION 8B-HC5-007-010 PANEL,DISPLAY 8B-HC5-043-010 WINDOW,DISPLAY 524 8B-HC5-009-010 KEY,PLAY 8B-HC5-001-010 LID,CD 8A-HC5-202-010 JOINT,LCD AHC5 8B-HC5-008-010 HLDR,LID CD 8B-HC5-011-110 KEY,MODE 8B-HC5-010-010 KEY,SKIP 8B-HC4-203-010 SPR-T,OPEN 8B-HC4-023-110 CABI,CENTER (V724)-B 8B-HC4-204-010 SPR-T,KNOB 8B-HC4-011-010 KNOB,SL OPEN 8B-HC4-205-010 LEVER,OPEN...

  • Page 15: Accessories / Package List

    ACCESSORIES / PACKAGE LIST REF. NO. PART NO. KANRI DESCRIPTION 1 8B-HC5-924-010 IB,HR(ECA)S 523<523AHR> 1 8B-HC5-922-010 IB,HR(ECA)S 524<524AHR> 1 8B-HC5-905-010 IB,EZ(EGF)S 522/523<522AEZ> 1 8B-HC5-916-010 IB,EZ(SID)S 522/523<522AEZ> 1 8B-HC5-907-010 IB,EZ(PHNCZ)S 522/523<522AEZ> 2 87-B30-285-110 AC ADAPTOR,AC-D603HRNC<523AHR,524AHR> 2 87-B30-283-110 AC ADAPTOR,AC-D603ENC<522AEZ> 3 87-B30-362-010 BAT,NB-305 NC(2PSC) 4 87-B30-326-210 HEADPHONE,HP-M048<522AHZ>...
  • Page 16 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9620450,0251431 Printed in Singapore...

This manual is also suitable for:

Xp-v523Xp-v524
