MODEL
AC SUPPLY
i1215BSBDUAL
120 volts, 60 Hertz
i1215BSBTRI
120 volts, 60 Hertz
i1215BSBQUAD
120 volts, 60 Hertz
i615BSBDUAL
120 volts, 60 Hertz
i615BSBQUAD
120 volts, 60 Hertz
* Total Series Capability - This refers to the Battery Pack. The charger will charge each individual battery within the
pack INDEPENDENTLY of the others within that same pack. The charger ignores the series connections.
Parallel Charging - The chargers can be hooked up to batteries that are connected in parallel, however the
batteries would not be treated independently. All banks of the charger would see the same voltage.
IMPORTANT NOTICE
Please save and read all safety, operating and installation instructions before installing
or applying AC power to your on-board battery charging system. Please contact us with
any product, installation, or service questions at technical support (800.742.2740).
INTRODUCTION
Pro Charging Systems, LLC (PCS) has been manufacturing high quality, high performance charging
systems since 1989. Our charging systems are designed and built tough to withstand intense vibration,
extreme environmental variations and without damaging the unit. Our systems use temperature
compensation in order to fully charge a battery in hot or cold environments and are controlled by
microprocessors in order to assure precise control over each totally independent charging bank. All of
our chargers have true reverse polarity protection and shut off completely after each charge cycle.
TABLE OF CONTENTS
Important Safety Instructions.............................................................. Pages 2-3
Product Summary................................................................................Pages 4-5
Installation Instructions........................................................................Pages 5-6
Trouble Shooting.................................................................................Page 7
Warranty Information...........................................................................Page 8
IMPORTANT SAFETY INSTRUCTIONS
Use of attachments not recommended or sold by PCS may result in a risk of fire, electrical shock, or injury
to persons.
To reduce risk of damage to the electrical plug and power cord, always pull by the plug rather than by the
power cord when disconnecting charger.
FOR THE FOLLOWING BATTERY CHARGING SYSTEMS:
DC Output
Two 15 amp Banks
Three 15 amp Banks
Four 15 amp Banks
Two 10 amp Banks
Four 10 amp Banks
Battery System
Total Series
Capability*
12 volt, 6 cell
12 volt, 6 cell
12 volt, 6 cell
6 volt, 3 cell
6 volt, 3 cell
2
Battery Capacity
24 volts
75-150 ah(20hr rating)
36 volts
75-150 ah(20hr rating)
48 volts
75-150 ah(20hr rating)
12 volts
75-150 ah(20hr rating)
24 volts
75-150 ah(20hr rating)
