- Page 1 L’esprit Modem User Guide GenPro 53e Reference : EG_GenPro53e_1040_UG_003_UK Revision : 003 Date : 05/07/2011 S.A. ERCO & GENER – ZI de St. Lambert-des-Levées – BP 30163 – F-49412 SAUMUR Cedex Tél. : +33 (0)2 41 83 13 00 – Fax : +33 (0)2 41 67 19 20 – www.ercogener.com – infos@ercogener.com...
- Page 2 - § 5.3.1.3 The application ERCO & GENER EasePro_Vx - § 7.2.2.2 Specifications of the internal battery - § 9.1 General security The GenPro 53e AOB becomes the GenPro 53e. Page 23, the modem does not FAX. 05/07/11 Updating limits - 8.2.2.3 Buzzer...
-
Page 3: Table Of Contents
EG_GenPro53e_1040_UG_003_UK Page 3 / 71 TABLE OF CONTENTS PRESENTATION ............................... 7 WARNING ................................. 8 COPYRIGHT ..............................9 1 REFERENCES ............................. 10 1.1 R ........................... 10 EFERRED DOCUMENTS 1.2 A ............................10 BBREVIATIONS 1.3 S .............................. - Page 4 EG_GenPro53e_1040_UG_003_UK Page 4 / 71 5.1.3.3 The application ERCO & GENER EasePro_Vx ..............27 5.1.3.4 The owner application ......................28 5.1.4 SIM card extraction ........................28 5.1.6 Hardware reset of the modem ....................... 28 5.2 S ............
-
Page 5: Eg_Genpro53E_1040_Ug_003_Uk
EG_GenPro53e_1040_UG_003_UK Page 5 / 71 7.2.3 Protections of the power supply ..................... 43 7.3 RS232 ..........................43 SERIAL LINK 7.3.1 General Presentation ........................43 7.3.2 Serial link RS232_0 ........................43 7.3.3 Serial link RS232_1 ........................44 ... - Page 6 EG_GenPro53e_1040_UG_003_UK Page 6 / 71 8.2.3.2 Output ............................. 62 8.2.3.3 Analog input ..........................63 8.2.4 SIM interface ..........................63 8.2.5 Option 2 SIM interface ........................ 63 8.2.6 RESET signal ..........................64 8.2.7 Characteristics of the RS232 serial links ..................64 ...
-
Page 7: Presentation
EG_GenPro53e_1040_UG_003_UK Page 7 / 71 Presentation Entirely dedicated to the wireless markets throughout the world, the GenPro 53e (Application On Board) allows a simple and rapid integration of GSM / GPRS Quad-Band (850/900/1800/1900 MHz) connectivity into M2M applications. GenPro 53e is a robust, reliable and long life product. -
Page 8: Warning
EG_GenPro53e_1040_UG_003_UK Page 8 / 71 Warning • ERCO & GENER advises to read carefully all the documents concerning the GenPro 53e (User Guide, Application Notes, Command List). • ERCO & GENER cannot be held responsible for: The problems due to an inappropriate use of the GenPro 53e. -
Page 9: Copyright
The reproduction, transfer, distribution or storage of part or the totality of the contents of this document, in any form, without the prior written authorization of ERCO & GENER is strictly prohibited. GenPro 53e is a trademark of ERCO & GENER. -
Page 10: References
Standard library of ERCO & GENER ......... : EG_EGM_CL_xxx_yy The embedded application EasePro of ERCO & GENER ..: EG_EasePro_Vx_CL_yyy_UK Application Notes of GenPro 53e of ERCO & GENER ....: EG_GenPro53e_1040_AN_xxx_yy GSM reference documents: ● GSM 07.05. ● GSM 07.07. - Page 11 EG_GenPro53e_1040_UG_003_UK Page 11 / 71 GPRS General Packet Radio Service Global Positioning System Global System for Mobile communications Half Rate Input International Electrotechnical Commission IMEI International Mobile Equipment Identification Input / Output Light Emitting Diode Low Level Command MAXimum Mobile Equipment MICrophone Micro FIT Family of connectors from Molex...
-
Page 12: Symbols
EG_GenPro53e_1040_UG_003_UK Page 12 / 71 1.3 Symbols The following symbols are used to highlight the important information of this userguide. A symbol for the essential information concerning the module integration and performance. A warning symbol indicates the actions that could harm or damage the module Descriptions and non-contractual illustrations in this document are given as an indication only. -
Page 13: Packaging
EG_GenPro53e_1040_UG_003_UK Page 13 / 71 2 Packaging 2.1 Content GenPro 53e is supplied: GenPro 53e cardboard packaging, - a modem GenPro 53e, - 2 fixing brackets, - a 4-wire supply cable, input/output (Red/Black/Yellow/Brown) stripped with fuse. - a 14-wire stripped cable Inputs/outputs with 14 pins connector. -
Page 14: Packing Case
EG_GenPro53e_1040_UG_003_UK Page 14 / 71 2.2 Packing case The external dimensions of the packing case are: - Width : 160 mm, - Height: 280 mm, - Length: 64 mm. A packaging label is placed on the side of the case. It shows: - The logo ERCO &... -
Page 15: General Presentation
EG_GenPro53e_1040_UG_003_UK Page 15 / 71 3 General presentation 3.1 Description Description of the modem GenPro 53e: 3.1.1 Front side 16pin/M 4pin/M Micro-Fit connector Micro-Fit connector 14pin/M Micro-Fit connector 3.1.2 Back side Audio connector RJ9 4/4 FAKRA-D connector GSM antenna GSM LED LED 3 LED 6 SIM card cover... -
Page 16: Fixing Brackets
EG_GenPro53e_1040_UG_003_UK Page 16 / 71 3.1.3 Fixing brackets 2 brackets to fix the modem on a support. Fixing brackets Descriptions and non-contractual illustrations in this document are given as an indication only. ERCO&GENER reserves the right to make any modifications... -
Page 17: External Connections
The GSM antenna connector is FAKRA D male with a 50Ω impedance. 3.2.1.2 Micro FIT connectors Female Micro FIT connector with 4 male pins: This connector of the GenPro 53e is a connector for the DC external supply and the GPIOs (the 2 signals Input and Output). Pin N°... - Page 18 EG_GenPro53e_1040_UG_003_UK Page 18 / 71 Female Micro FIT connector with 14 male pins: This connector of the GenPro 53e is a connector for the inputs, logical and analog outputs. Pin N° type Nature Signal Option* Logical ONE_WIRE Input Analog ANA2...
-
Page 19: Audio Connector
EG_GenPro53e_1040_UG_003_UK Page 19 / 71 Female Micro FIT connector with 16 male pins: This connector of the GenPro 53e is a connector for the serial links 0, 1,2 or bus CAN (option) and control signal BOOT, RESET. Pin N° type... -
Page 20: Cables
EG_GenPro53e_1040_UG_003_UK Page 20 / 71 3.2.2 Cables 3.2.2.1 4-wire micro FIT cable Fuse 2A/32V 3mm tinned and (ERCO & GENER reference: 4402304215) (Mini BLADE) stripped wire Component Characteristics 4-pin connector Cable Length ≈ 1.5m Wire Section : 0.75 mm² Fuse F2A - 32V Signal Color... -
Page 21: 14-Wire Micro Fit Cable
EG_GenPro53e_1040_UG_003_UK Page 21 / 71 3.2.2.2 14-wire micro FIT cable 3mm tinned stripped wire ( ERCO & GENER reference: 4402314215) (Mini BLADE) View from cable side Component Characteristics 14-pin connector Cable Length ≈ 1.5m Wire Section : 0.5 mm² Pin N° Signal Color ONE_WIRE... -
Page 22: 16-Wire Micro Fit Cable
EG_GenPro53e_1040_UG_003_UK Page 22 / 71 3mm tinned and 3.2.2.3 16-wire micro FIT cable stripped wire (Mini BLADE) ( ERCO & GENER reference : 4404314215) Component Characteristics 16-pin connector Cable Length ≈ 1.5m Wire Section : 0.5 mm² Sub D 9-pin female View from cable side Pin N°... -
Page 23: Characteristics And Services
EG_GenPro53e_1040_UG_003_UK Page 23 / 71 4 Characteristics and Services GenPro 53e A class10 GSM/GPRS modem dedicated to asynchronous binary data transmission, Group3 (Class 2), SMS and voice. The modem characteristics and the available services are summarized in the table below. - Page 24 EG_GenPro53e_1040_UG_003_UK Page 24 / 71 Accessories supplied - Fixing brackets (x2) - 4-wire Micro FIT cables (Power supply, Input and Output ) - 14-wire Micro FIT cables (Input and Output) - 16-wire Micro FIT cables (serial ports) Options / Accessories * - Power supply 100 Volts - Direct logical inputs - Powering on controllable by HTR...
-
Page 25: Using The Modem
EG_GenPro53e_1040_UG_003_UK Page 25 / 71 5 Using the modem 5.1 Starting with the modem 5.1.1 Mounting the modem To mount the modem on a support, use the fixing brackets as described below. - Must be fixed on a flat surface - Max. -
Page 26: Checking The Communication With The Modem
- The owner application. 5.1.3 Checking the communication with the modem 5.1.3.1 Without Application GenPro 53e does not contain any application; it will return the menu of the Boot-Loader. Connect the link RS232 between the DTE (the COM port) and the modem (DCE). -
Page 27: Standard Library
EG_GenPro53e_1040_UG_003_UK Page 27 / 71 5.1.3.2 Standard library GenPro 53e contains the standard library. Connect the RS232 link between the DTE (the COM port) and the modem (DCE). Set the RS232 port of the DTE as follows: ▪ Bits per second: 115 200 bps, ▪... -
Page 28: The Owner Application
EG_GenPro53e_1040_UG_003_UK Page 28 / 71 5.1.3.4 The owner application GenPro 53e contains your application. Connect the RS232 link between the DTE (the COM port) and the modem (DCE). Set the RS232 port of the DTE according to your parameters (speed, data bits, parity and stop bit). -
Page 29: Recommended Connection On The Battery Of A Truck
EG_GenPro53e_1040_UG_003_UK Page 29 / 71 5.2.1 Recommended connection on the battery of a truck All lorries have a Circuit Breaker outside the cabin. The circuit breaker is used for security reasons: for example, if a fire breaks out in the electric box of the lorry, the driver can cut off the power source and avoid more damage (explosion). -
Page 30: Technical Constraints In Trucks
EG_GenPro53e_1040_UG_003_UK Page 30 / 71 5.2.2 Technical constraints in trucks It is highly recommended NOT to connect the modem supply directly to the battery but to the circuit breaker. Otherwise the modem can be damaged when the lorry is starting up if the circuit breaker is closed (in this case, the ground of the lorry and the ground of the battery will be connected via the modem as described in the scheme below). -
Page 31: Modem Leds
EG_GenPro53e_1040_UG_003_UK Page 31 / 71 5.3 Modem leds 5.3.1 GSM led 5.3.1.1 Without application GenPro 53e does not contain any application. The led is off. 5.3.1.2 With standard library GenPro 53e contains the standard library. The led is off. 5.3.1.3 The application ERCO & GENER EasePro_Vx The GSM status module is indicated by the GSM LED located on the rear side of the modem. -
Page 32: Led 5
EG_GenPro53e_1040_UG_003_UK Page 32 / 71 5.3.4 Led 5 This led is free. It is left at the user’s disposal. It is controlled via a command through the ARM. This command is currently under development. Contact us. 5.3.5 LED 6 This led is not used. 5.4 Echo function of the deactivated AT commands The modem contains the EGM standard library (see the documents "EG_EGM_CL_xxx_yy"... -
Page 33: Verification Of The Pin Code
EG_GenPro53e_1040_UG_003_UK Page 33 / 71 To check the quality of the GSM signal, do the following operations: Use a communication software like Hyperterminal, enter the command AT+CSQ. The response is in the following format: +CSQ : <rssi>, <ber> with: <rssi> = indicates the reception level, <ber>... -
Page 34: Verification Of The Modem Registration On The Gsm Network
EG_GenPro53e_1040_UG_003_UK Page 34 / 71 5.7 Verification of the modem registration on the GSM network The modem contains the EGM standard library (see the documents "EG_EGM_CL_xxx_yy" of ERCO & GENER) in this case: 1. Ensure that a valid SIM card has been inserted in the SIM card reader of the modem. 2. -
Page 35: Main At Commands (Hayes)
EG_GenPro53e_1040_UG_003_UK Page 35 / 71 5.8 Main AT commands (HAYES) The modem contains the EGM standard library (see the documents "EG_EGM_CL_xxx_yy" of ERCO & GENER) in this case, the table below shows the main AT commands necessary for the control of the modem. -
Page 36: Turning Off The Modem
And cut the external power supply of the modem. • If the modem does not contain any embedded application, via the Boot-Loader menu Bootloader V2.39 GL53 UA GenPro 53e ENF (HW16 rev B/C) GSM voltage = 4330 mV 1 - Update application... -
Page 37: Trouble Shooting
Is the modem without echo and Send the command ATE1Q0 followed by AT&W without message reporting? if a backup is required . * only if the GenPro 53e has EasePro_Vx application Descriptions and non-contractual illustrations in this document are given as an indication only. -
Page 38: Error" Message
The modem returns a message "ERROR" (in response to an AT command) in the following cases: ▪ The COM port is not directed to the modem GenPro 53e but to another modem. Enter ATI1, and the response must be Enabler_III..Any other response indicates a dialog with another modem. In this case, check the COM port used in the Hyperterminal. - Page 39 EG_GenPro53e_1040_UG_003_UK Page 39 / 71 Table: Solutions when a message "NO CARRIER” is returned If the modem... Check : Action "NO CARRIER" Is the received GSM signal strong See the paragraph 5.5 to check the quality of the enough? received signal . Is the modem registered on the See the paragraph 5.7 to check the registration network?
-
Page 40: Functional Description
EG_GenPro53e_1040_UG_003_UK Page 40 / 71 7 Functional Description 7.1 Architecture 7.2 Power supply 7.2.1 General presentation The modem must be powered by an external DC tension (V+BATTERY) between +5.5V and +32V. The regulation of the modem power supply is made with a DC/DC internal converter in order to supply all the necessary internal DC tensions. -
Page 41: Internal Battery
GenPro 53e. This battery allows to maintain the GenPro 53e functioning in the absence of its external power supply (power supply connected on the Micro-FIT 4-pin female connector). The internal charging circuit allows to keep permanently the charge of the battery from the external power supply. -
Page 42: Indication Of Presence/Absence Of The External Power Supply
EG_GenPro53e_1040_UG_003_UK Page 42 / 71 7.2.2.4 Indication of presence/absence of the external power supply The modem contains the EGM standard library (see the documents "EG_EGM_CL_xxx_yy" of ERCO & GENER) in this case, the command AT+GPIOGET=27 allows to know the status of the external power supply for the internal battery. -
Page 43: Protections Of The Power Supply
The RS232 interface was designed to allow a certain flexibility in the use of the serial interface signals. In fact, after the setting (see command AT+IFC) if the GenPro 53e contains the EGM standard library (see the documents "EG_EGM_CL_xxx_yy" of ERCO & GENER) in this case, the modem can work in 3-wire mode (using only the signals TX, RX, GND), but the use of the signals TX, RX, GND, CTS, RTS is required for a GPRS application. -
Page 44: Serial Link Rs232_1
EG_GenPro53e_1040_UG_003_UK Page 44 / 71 Normalized signals of a RS232_0 serial link Pins description 16-pin micro FIT Sub D 9-pin RS232 Signal connector Description connector standard Pins number Pins number CT103 / TX_0 Transmit serial data CT104 / RX_0 Receive serial data CT105 / RTS_0 Request To Send CT106 / CTS_0... -
Page 45: Serial Link Rs232_2 / Bus Can
EG_GenPro53e_1040_UG_003_UK Page 45 / 71 Micro FIT 16-pin RS232 Signal connector Description Color of wire standard Pins number CT103 / TX_1 Transmit serial data White/Green CT104 / RX_1 Receive serial data White /Blue CT105 / RTS_1 Request To Send White /Yellow CT106 / CTS_1 Clear To Send White /Brown... -
Page 46: Bus Can
Ground Black 7.4 Inputs/Output functioning GenPro 53e provides five Inputs (opto-coupled), three Outputs (open collector) and two analog Inputs available for an external use. As an option (contact us) the inputs E3 and E5 can be insulated. The modem contains the EGM standard library (see the documents "EG_EGM_CL_xxx_yy" of ERCO &... -
Page 47: Management Of Logical Outputs
EG_GenPro53e_1040_UG_003_UK Page 47 / 71 7.4.1 Management of logical outputs The modem contains the EGM stand ard library (see the documents "EG_EGM_CL_xxx_yy" of ERCO & ER) in this case, these function s are controlled by AT commands. GPIOSET This command is used to drive the output. -
Page 48: Management Of Analog Inputs
EG_GenPro53e_1040_UG_003_UK Page 48 / 71 See table of the paragraph 8.2.3.1 Opto-coupled inputs for the characteristics of use of the Inputs/Output 7.4.3 Manag ement of analo g inputs he commands for the management of analog inputs are currently under development. Contact us. See table of the paragraph 8.2.3.3 Analog input for the characteristics of use of the Inputs/Output... -
Page 49: Reset Sequence
EG_GenPro53e_1040_UG_003_UK Page 49 / 71 in description 14-pin connector Pins Signal Type I/O Description number RES T SCHMITT Reset Modem The use of the RESET function is strictly reserved to the manufacturers and distributors. This signal must be used only in case of emergency RESET. A software RESET is always preferable to a Hardware RESET. -
Page 50: Watchdog
Page 50 / 71 7.8 WatchDog The Hardware WatchDog function allows the surveillance of the GenPro 53e software activity: the Software management of the WatchDog is implanted in the embedded application by default. In the case of a development (EGM) it must be implanted in the embedded application of the final customer. -
Page 51: Loud-Speaker Outputs (Speaker)
Negative output of loudspeaker Recommended characteristics for the loudspeaker 7.9.3 Buzzer outputs By default, the GenPro 53e provides a Buzzer output on the output 14 of the 14-pin connector. This output provides a frequency, it is dedicated to drive a Transducer. Pin description... -
Page 52: Accelerometer
EG_GenPro53e_1040_UG_003_UK Page 52 / 71 7.10 Accelerometer GenPro 53e provides an accelerometer with 3 axis of sensitivity ±2G or ±8G controllable by software. Positioning of the axis 7.11 Internal processor 7.11.1 EGM presentation GenPro 53e provides an ARM7 processor that allows to have an embedded application developed from the EGM libraries and based on eCos. -
Page 53: Egm Architecture
EG_GenPro53e_1040_UG_003_UK Page 53 / 71 7.12.2 EGM architecture The software architecture is described below. For more information about EGM, see the documents ERCO & GENER for a description of the different functionalities. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCO&GENER reserves the right to make any modifications... -
Page 54: Technical Characteristics
EG_GenPro53e_1040_UG_003_UK Page 54 / 71 8 Technical characteristics 8.1 Mechanical characteristics 95 x 92 x 40 mm ( excluding the connectors ) Dimensions 104 x 92 x 40 mm Complete dimensions ≈ 206 grams (modem only) Weight < 618 grams (modem + brackets + cables) Volume ≈... -
Page 55: Electrical Characteristics
EG_GenPro53e_1040_UG_003_UK Page 55 / 71 8.2 Electrical characteristics 8.2.1 Power supply Table: Electrical characteristics 5.5V to 32V DC Power supply range Conditions Battery charged 28 mA @ 12V GSM OFF Battery in charge Average consumption 151 mA @ 12V GSM OFF - 900 MHz .. -
Page 56: Consumption Of The Board With Battery Charged
EG_GenPro53e_1040_UG_003_UK Page 56 / 71 For example: The equipment is supplied with 12V with - the battery charged - RS 232 connected - The GSM module in GPRS communication at 900 MHz I Nom.(mA) I Pic.(mA) Board 191.3 Total : 222.5 The average consumption is 222.5 mA and the power supply must support current peaks of 804 mA. -
Page 57: Consumption Of The Rs 232
EG_GenPro53e_1040_UG_003_UK Page 57 / 71 8.2.1.3 Consumption of the RS 232 Table: Consumption of the RS 232 connection CONDITIONS +VDC I Nom.(mA) T=25°C Battery charged @ 5,5V GSM OFF @ 12V RS 232 disconnected @ 24V @ 32V (1*) The consumptions of the power supply may vary by 5% depending on the temperature range (-20 °C to +55 °C). Typical value with a portable computer. -
Page 58: Audio Interface
EG_GenPro53e_1040_UG_003_UK Page 58 / 71 8.2.2 Audio interface The audio interface is available via the RJ 9 4/4 connector, (see paragraph 7.9.1 Microphone inputs, 7.9.2 Loud-speaker outputs (Speaker)) and pin 14 of the 14-pin connector for the Buzzer (see paragraph 7.9.3 Buzzer outputs ). -
Page 59: Loudspeaker
EG_GenPro53e_1040_UG_003_UK Page 59 / 71 8.2.2.2 Loudspeaker Output characteristics for the loudspeaker Loudspeaker output Parameters/Conditions Units Output Swing 3.9 V Ω Maximum Differential Resistive Load Output Swing 1.5 V Ω Maximum Differential Capacitive Load Common Mode Minimum At Internal Speaker (+) or (-) kΩ... -
Page 60: Buzzer
= 0; VCB = 10 V; f = 1 MHz total power dissipation ≤ 25 °C Ttot Example of transducer tested with the GenPro 53e Buzzer characteristics Values Type Transducer AT-2720-T-R Consumptions 1-30V peak/3.5mA max. Resonance frequency 2.048Hz ±500HZ... -
Page 61: Inputs/Output
EG_GenPro53e_1040_UG_003_UK Page 61 / 71 8.2.3 Inputs/Output By default, the GenPro 53e provides 5 opto-coupled inputs (E1 to E5) 3 open collector outputs (S1 to S3). 2 analog inputs (ANA1, ANA2). 8.2.3.1 Opto-coupled inputs Table: Characteristics of opto-coupled inputs Characteristics... -
Page 62: Output
EG_GenPro53e_1040_UG_003_UK Page 62 / 71 As an option (contect us) the inputs E3 and E5 can be insulated. Input pins pins E3 insulated E5 insulated 8.2.3.2 Output Table: Characteristics of the open-collector output Characteristics Symbols Conditions Max. Unit max.Tension Open transmitter max.Tension = 0 V Collector current... -
Page 63: Eg_Genpro53E_1040_Ug_003_Uk
EG_GenPro53e_1040_UG_003_UK Page 63 / 71 8.2.3.3 Analog input Table: Characteristics of the option analog input Characteristics Symbols Conditions Min. Typ. Max. Unit Analog input ANA1 / 2 -0.3 10.8 Conversion range 1.3 µ 10.33 Polarization current From 1.3 µV to 10.33 V 0.064 µA The integrator has the responsibility to protect the input from electrical perturbations and to... -
Page 64: Reset Signal
EG_GenPro53e_1040_UG_003_UK Page 64 / 71 8.2.6 RESET signal Cabling scheme You must pass through a transistor assembly to use the RESET signal. Table: Conditions of use Parameters Condition Min. Typ. Max. Unit Input Voltage – Low -0.3 Input Voltage – High RIPU Internal Pull-Up Resistor 5.38K... -
Page 65: Rf Gsm/Dcs Characteristics
EG_GenPro53e_1040_UG_003_UK Page 65 / 71 8.2.8 RF GSM/DCS characteristics 8.2.8.1 RF functioning The RF functioning complies with the ETSI GSM Standards. The RF performances for the receiver and the transmitter are described below. Table: Parameters of the RF receiver and transmitter Receiver Sensitivity in 850/900 - 106 dBm, GPRS Coding Scheme 1 (CS1) -
Page 66: Power Supply 3.8 V
With power supply 5.5V - 32V Iout Max. * The GenPro 53e works only with battery. The min. 2.8 V auto-protection limit of the battery. From this moment, the battery puts itself under protection, and the output tension becomes null. -
Page 67: Standards/Conformities
EG_GenPro53e_1040_UG_003_UK Page 67 / 71 8.4 Standards/Conformities The product complies with the following requirements: - R&TTE 1999/5/EC Directive, - Regulations of standard ETSI EN 301 489-7 (02), - ROHS Compliant : Directive 2002/95/CE, - 2002/96/CE DEEE (crossed out wheelie bin). The following marking appears under the device. -
Page 68: Security Recommendations
EG_GenPro53e_1040_UG_003_UK Page 68 / 71 9 Security recommendations 9.1 General security It is important to respect the specific regulations concerning the use of radio equipment, in particular with the possible risks of interference due to radio frequency (RF). Please respect carefully the following security advices. -
Page 69: Security In A Vehicle
EG_GenPro53e_1040_UG_003_UK Page 69 / 71 9.2 Security in a vehicle Do not use your Modem whilst driving, unless equipped with a correctly installed ear-piece/hands-free kit. Respect the national regulations concerning the use of cellular telephones in vehicles. Road safety is always a priority. -
Page 70: Recommended Accessories
EG_GenPro53e_1040_UG_003_UK Page 70 / 71 10 Recommended Accessories The accessories recommended by ERCO & GENER for the modem GenPro 53e, are described on our website in the section Products/Accessories. For more information, contact our sales department. 11 Client support ERCO & GENER ensures the client support for all its modems sold. You will then have access to: The latest version of this document The datasheet of the product The latest versions of the OS user guides... -
Page 71: Declaration Of Conformity
B.P. 30163 49412 SAUMUR CEDEX – France Website : http://www.ercogener.com declares that the product : Name : Type : GenPro 53e Modem Complies with : Safety : The corresponding markings appear under the appliance. Saumur, --- -- Charles CHAUSSONNIER Managing Director S.A.
