User Guide
Reference : EG_GenPro18e_1003_UG_007_UK
Revision :
Date :
S.A. ERCO & GENER – ZI de St. Lambert-des-Levées – BP 30163 – F-49412 SAUMUR Cedex
Tél. : +33 (0)2 41 83 13 00 – Fax : +33 (0)2 41 67 19 20 – www.ercogener.com – infos@ercogener.com
€
SA CAPITAL 200873
– R.C. SAUMUR B 332 174 820 – SIRET 332 174 820 00032 – NAF 2630Z – TVA Intra : FR 16 332 174 820
GenPro 18e
(GenPro18e)
007
10/10/2011
L'esprit Modem
Advertisement
Table of Contents
Related Manuals for Erco & Gener GenPro 18e
Summary of Contents for Erco & Gener GenPro 18e
- Page 1 L’esprit Modem User Guide GenPro 18e (GenPro18e) Reference : EG_GenPro18e_1003_UG_007_UK Revision : Date : 10/10/2011 S.A. ERCO & GENER – ZI de St. Lambert-des-Levées – BP 30163 – F-49412 SAUMUR Cedex Tél. : +33 (0)2 41 83 13 00 – Fax : +33 (0)2 41 67 19 20 – www.ercogener.com – infos@ercogener.com €...
-
Page 2: Document History
F. LE BRETON 30/10/09 Updating the certificate of conformity. 10/05/11 The GenPro 20e SQB becomes the GenPro 18e. 10/10/11 The main modifications in this document compared to its previous version, are easily identifiable on a monitor by means of the blue text. -
Page 3: Table Of Contents
EG_GenPro78e_1003_UG_007_UK Page 3 / 41 CONTENTS PRESENTATION ..............................5 WARNING ................................6 COPYRIGHT AND DISCLAIMER ........................6 1 REFERENCES ..............................7 1.1 R ..........................7 EFERENCE OCUMENTS 1.2 A ............................... 7 BREVIATIONS 2 PACKING ................................. 9 ... - Page 4 EG_GenPro78e_1003_UG_007_UK Page 4 / 41 7.3.1 General ............................29 7.3.2 Auto-baud mode ..........................30 7.3.3 Auto-power supply mode through the pin RI ................. 30 7.3.4 Pins description ..........................30 7.4 A ................................. 31 UDIO 7.4.1 Microphone ............................ 31 ...
-
Page 5: Eg_Genpro78E_1003_Ug_007_Uk
EG_GenPro78e_1003_UG_007_UK Page 5 / 41 Presentation Entirely dedicated to the wireless markets throughout the world, the GenPro 18e allows a simple and rapid integration of GSM / GPRS connectivity into M2M applications. GenPro 18e is a robust, reliable and long life product. Its very compact metal case makes it ideally adapted to onboard standards. -
Page 6: Warning
ERCO & GENER is strictly prohibited. GenPro 18e is a trademark of ERCO & GENER. Hayes is a registered trademark of Hayes Microcomputer Product Inc. The names of products and companies mentioned in this document may be names or trademarks of their respective holders. -
Page 7: References
EG_GenPro78e_1003_UG_007_UK Page 7 / 41 1 References 1.1 Reference Documents AT Commands Lists: EG_GenProxxx_ xxx_1003_CL_000_UK Software update procedure: EG_GenProxxx_xxx_1003_UP_000_UK Documents de reference GSM: ● GSM 07.05. ● GSM 07.07. 1.2 Abreviations Alternative Current Accumulated Call Meter Adaptative Multiple Rate Attention (prefix for modem commands) Base Transceiver Station ClocK CMOS... - Page 8 EG_GenPro78e_1003_UG_007_UK Page 8 / 41 IMEI International Mobile Equipment Identification Input / Output Light Emitting Diode MAXimum Mobile Equipment MICrophone Micro FIT Family of connectors from Molex MINimum Microcom Networking Protocol Mobile Originated Mobile Station Mobile Terminated NOMinal Output Pascal (for speaker sound pressure measurements) PBCCH Packet Broadcast Control Channel Personal Computer...
-
Page 9: Packing
EG_GenPro78e_1003_UG_007_UK Page 9 / 41 2 Packing 2.1 Contents GenPro 18e is supplied with: GenPro 18e packing case, GenPro 18e modem, - 2 fixing brackets, - Instructions Sheet. - 2-wire cable (Red/Black) with in-line fuse 2.2 Packing Case Packing case external dimensions: - Width: 54.5 mm,... -
Page 10: Modem Labels
EG_GenPro78e_1003_UG_007_UK Page 10 / 41 2.3 Modem Labels One production label, attached to the underside of the modem, provides the following information: - CE mark, - Crossed wheelie-bin mark (DEEE standard), - DC supply (VDC), - The IMEI 15-digit bar code. Description and non-contractual illustrations in this document are given as an indication only. -
Page 11: General Presentation
EG_GenPro78e_1003_UG_007_UK Page 11 / 41 3 General Presentation 3.1 Physical Description Description of the GenPro 18e modem: Connector Micro-Fit 4pins/M Front side Connector Sub HD 15pins/F Rear side Connector SMA/F SIM card cover GSM LED Two fixing brackets for attaching the modem to a support: Brides de fixation Description and non-contractual illustrations in this document are given as an indication only. -
Page 12: External Connections
EG_GenPro78e_1003_UG_007_UK Page 12 / 41 3.2 External connections 3.2.1 Connections 3.2.1.1 GSM antenna connector The GSM antenna connector is a 50Ω impedance female SMA type. 3.2.1.2 4-pins Micro FIT female connector This connector allows the connection of an external DC supply. Pin N°... -
Page 13: 2-Wire Micro Fit Supply Cable
EG_GenPro78e_1003_UG_007_UK Page 13 / 41 3.2.2 2-wire micro FIT supply cable This cable provides power to the modem. Component Characteristics 4-pin Micro FIT connector Type : MOLEX Cable Length ≈ 1.5m Wire Tinned copper 24 x 0.2 mm Surface area : 0.75 mm² Description and non-contractual illustrations in this document are given as an indication only. -
Page 14: Characteristics And Services
EG_GenPro78e_1003_UG_007_UK Page 14 / 41 4 Characteristics and Services GenPro 18e is a class 10 GSM or GSM/GPRS modem intended for asynchronous binary data transmission, fax Group3 (Class 2), SMS and voice. The features of the GenPro 18e modem are shown in the table below. -
Page 15: Using The Modem
EG_GenPro78e_1003_UG_007_UK Page 15 / 41 5 Using The Modem 5.1 Starting with the modem 5.1.1 Mounting the modem To mount the modem on a support, use the fixing brackets as shown in the diagram below: Note: - Must be fixed to a flat surface. -
Page 16: Communication With The Modem
EG_GenPro78e_1003_UG_007_UK Page 16 / 41 5.1.3 Communication with the modem Connect the RS232 cable between the DTE (the COM port) and the modem (DCE). Configure the DTE RS232 port as follows: ▪ Data rate: 9600 bps, ▪ Data size: 8 bits, ▪... -
Page 17: Re-Initialisation Of The Modem
For further details concerning the RESET of the modem, see the chapter 7.6 RESET. 5.2 Recommendations for using the modem in vehicles WARNING: The power supply connector on the GenPro 18e must NOT be connected directly to the battery of a vehicle. 5.2.1 Recommended connection to the battery in a lorry All Lorries have a circuit breaker outside the cabin. - Page 18 EG_GenPro78e_1003_UG_007_UK Page 18 / 41 GenPro 18e The diagram above shows a recommended connexion, where the modem is connected after the circuit breaker to the ground of the lorry (or in the fuse box) and NOT directly to the earth of the battery Description and non-contractual illustrations in this document are given as an indication only.
-
Page 19: Technical Constraints In Lorry
Otherwise the modem may be damaged when the lorry is starting and the circuit breaker is closed. In this case the ground of the lorry and the ground of the battery will be connected together via the modem as shown in the diagram below: GenPro 18e Example of a forbidden... -
Page 20: Gsm Indicator Led
EG_GenPro78e_1003_UG_007_UK Page 20 / 41 5.3 GSM indicator LED The state of the modem is indicated by the GSM LED located on the rear side of the modem, close to the SIM holder (see chapter 3.1 Physical Description). The table below shows the meaning of the different states of the GSM LED : GSM LED LED activity Modem state... -
Page 21: Verifying Gsm Receive Signal Quality
EG_GenPro78e_1003_UG_007_UK Page 21 / 41 5.5 Verifying GSM receive signal quality The modem will be able to establish a call only if the received GSM signal is of a sufficient level. The command AT+CSQ will return the reception level (rssi) of the signal sent by the closest GSM Base Transceiver Station (BTS), as well the receive bit error rate (ber). -
Page 22: Verifying The Pin Code
EG_GenPro78e_1003_UG_007_UK Page 22 / 41 5.6 Verifying the PIN code The PIN code is essential in order to make a call or to accept a call from the GSM network. The PIN code is held on the SIM card and can be modified by the user. To verify a previously entered PIN code, use a communication application and enter the command AT+CPIN? The table below shows the main responses from the modem:... -
Page 23: Main At Commands (Hayes)
EG_GenPro78e_1003_UG_007_UK Page 23 / 41 5.8 Main AT commands (HAYES) The table below shows at a quick glance the main AT commands useful for the control of the modem. For further information concerning the complete command set see the ERCO&GENER "Commands List”. Table: Main AT commands used with the modem. -
Page 24: Powering Down The Unit
Page 24 / 41 5.9 Powering down the unit There is no specific AT command to be transmitted to the GenPro 18e modem before removing the power. 5.10 Updating the modem software So as to be able to benefit from the latest functions of the... -
Page 25: Trouble Shooting
The modem returns the message “ERROR” (in response to an AT command) in the following cases : • The COM port is not directed to the GenPro 18e but to another modem. Enter the command ATI1. The response should be Enabler_III..All other responses indicate a dialog with another modem. -
Page 26: No Carrier" Message
EG_GenPro78e_1003_UG_007_UK Page 26 / 41 Enter the command AT+CMEE=1 to obtain an error message with its error code instead of a simple “ERROR” message, Enter again the AT command which previously caused a problem to obtain the error code. In the case of an error, the response is in the form : +CME ERROR : <error code>... -
Page 27: Functional Description
EG_GenPro78e_1003_UG_007_UK Page 27 / 41 7 Functional description 7.1 Architecture Description and non-contractual illustrations in this document are given as an indication only. ERCO & GENER reserves the right to make any modifications. -
Page 28: Power Supply
EG_GenPro78e_1003_UG_007_UK Page 28 / 41 7.2 Power supply 7.2.1 General The modem must be powered (V+BATTERY) by an external regulated DC power source of between 5.5V and 32V. The modem’s various internal DC voltages are provided by an internal DC/DC converter. The correct functioning of the modem cannot be guaranteed if the input voltage (V+BATTERY) falls below 5.5V. -
Page 29: Rs232 Serial Link
EG_GenPro78e_1003_UG_007_UK Page 29 / 41 7.3 RS232 serial link 7.3.1 General The RS232 interface provides a level translation (V24/CMOS ⇔ V24/V28) between the GSM module DCE) and the PC COM port (DTE). The RS232 interface is protected internally (ESD protection) against external electrostatic spikes. Filter guarantees: Input/output EMI/RFI protection, Signal smoothing. -
Page 30: Auto-Baud Mode
The auto-baud mode is controlled by the command AT+IPR. This function is explained in detail in the ERCO & GENER “Commands List”. Note: By default, the GenPro 18e is delivered with the RS232 interface configured to 9600 bps, no parity, 8 data bits, 1 stop bit. -
Page 31: Audio
EG_GenPro78e_1003_UG_007_UK Page 31 / 41 7.4 Audio The audio interface is a standard interface for connecting a telephone handset (the command AT$VSELECT enables you to select the handset, please refer to ERCO & GENER "Commands List"). Echo cancellation (see command AT$MICAEC) and noise reduction features are also available to improve the audio quality in hands-free applications. -
Page 32: Loud-Speaker
EG_GenPro78e_1003_UG_007_UK Page 32 / 41 7.4.2 Loud-speaker Differential outputs are used to help reduce common–mode and TDMA noise. The loud-speaker may be connected directly to the output pins. Table: Pins description Pin number Sub HD Signal name Type Description Connector CSPK2P Analogue Loud-speaker +ve... -
Page 33: Technical Characteristics
EG_GenPro78e_1003_UG_007_UK Page 33 / 41 8 Technical Characteristics 8.1 Mechanical Table: Mechanical characteristics Dimensions 73 x 54.5 x 25.5 mm (excluding connectors) Overall Dimensions 90 x 54.5 x 25.5 mm ≈ 88 grams (modem only) Weight < 197 grams (modem + fixing brackets + cables) Volume 101.5 cm³... -
Page 34: Electrical
EG_GenPro78e_1003_UG_007_UK Page 34 / 41 8.2 Electrical 8.2.1 Power supply Table: Voltage range and power consumptions Operating voltage range 5.5V to 32V DC (GSM or DCS or GPRS) - GSM 900 MHz : 90mA @ 12V in communication Average power consumptions - GSM 1800 MHz : 80mA @ 12V in communication - Idle mode : 12mA @ 12V Note : The modem is permanently powered once the power supply is connected. -
Page 35: Audio Interface
EG_GenPro78e_1003_UG_007_UK Page 35 / 41 8.2.2 Audio interface The audio interface is accessible via the 15-pin Sub HD connector (see chapter 7.4). Table: Characteristics of the audio interface on the 15-pin Sub HD connector Mic Input Parameter/Conditions Units Maximum Input Range – Inputs 3 dBm0 (Max. -
Page 36: External Gsm Antenna
EG_GenPro78e_1003_UG_007_UK Page 36 / 41 8.2.4.2 External GSM Antenna The external GSM antenna is connected to the modem via the SMA/M connector. It must have the characteristics listed in the table below. Table: External GSM antenna characteristics Antenna frequency range 850/900/1800/1900 MHz Impedance 50 Ohms nominal DC Impedance 0 Ohm Gain (antenna + cable) 0 dBi (in a minimum direction) VSWR (Rx max TX max) 1.5:1 Polarisation Linear... -
Page 37: Environmental Characteristics
EG_GenPro78e_1003_UG_007_UK Page 37 / 41 8.3 Environmental characteristics To ensure the correct operation of the modem, the limits listed in the table below should be respected. Table: Environmental characteristics Operating temperature -20 °C to +60 °C Storage temperature -30 °C to +85 °C Operating humidity without condensation HR <... -
Page 38: Security Recommendations
EG_GenPro78e_1003_UG_007_UK Page 38 / 41 9 Security Recommendations 9.1 General It is important to follow the specific regulations for the use of radio operator equipment, in particular the possible risks of radio frequency interference (RFI). Please follow carefully the security advice given below. Turn off your GSM modem: •... -
Page 39: Security In A Vehicle
EG_GenPro78e_1003_UG_007_UK Page 39 / 41 9.2 Security in a vehicle Do not use your GSM modem whilst driving a vehicle, unless equipped with a correctly installed ear- piece/hands-free kit. Respect the national regulations for the use of cellular telephones in vehicles. Road safety is always a priority. -
Page 40: Recommended Accessories
EG_GenPro78e_1003_UG_007_UK Page 40 / 41 10 Recommended Accessories The accessories recommended by ERCO & GENER for use with the GenPro modem are shown on our Internet site in the section Products > Accessories. For more information, contact our sales department. 11 Client support ERCO &... -
Page 41: Declaration Of Conformity
Z.I. de Saint Lambert des Levées B.P. 30163 49412 SAUMUR CEDEX – France Website: http://www.ercogener.com declares that the products : Name: GenPro 18e Type: Modem Complies with : - R&TTE 1999/5/EC Directive, - EN301489-1:V1.8.1 - EN301489-7:V1.3.1 - §6.5, §6.6, §6.8 and §6.9 of the 2004/104/CE directive - EN 301 511 v9.0.2...
