Summary of Contents for Nordic EFFECTA LAMBDA 35
- Page 1 EFFECTA LAMBDA 35 INSTALLATION MAINTENANCE SERVICE ASSEMBLY Rev.EA. 012-05-30...
-
Page 2: The Nordic Ecolabel
As a user of an ecolabeled product, you will contribute to a better environment around you. Wood system In order to fulfil the Nordic Ecolabel, the accumulator tank volume must be at least 2,000 litres. This to the boiler can burn at a high power output for a long time. Wood and solar system The solar collectors that are part of the ecolabeled total solution constitute an important part, but are not necessary for ecolabelling. -
Page 3: Table Of Contents
Contents ▀ The Nordic Ecolabel Contents Warranty General To the installer System parts System parts Environment Component placement Technical data Function Laddomat 21-60 Sleeve placement Accumulator BBS First firing Firing cycle Menus Electrical installation Cleaning and service Cleaning Lever cleaning... -
Page 4: Warranty
Warranty ▀ Products from Effecta are guaranteed free of defects with regards to materials and workman- ship for two years for wear parts such as gaskets, pumps, ceramics and electrical compo- nents from the date of installation. The wood boiler's welded body has a warranty period of five years. -
Page 5: General
▀ General Effecta Lambda is a wood boiler with an induced-draught fan. The boiler is fired with wooden logs measuring 50 cm. The boiler must be docked to one or more accumulator tanks, which are charged with charging equipment of the Laddomat 21-60 type or equivalent. Hot water is taken from the top of the boiler and is conducted to the accumulator tank. -
Page 6: To The Installer
To the installer ▀ It is time to install the Effecta Lambda wood boiler. Please follow the examples we provide for a safe installation. After installation, be sure to instruct the customer on how the heating system and the boiler work, in order to avoid unnecessary complications in the future. Set up The boiler is positioned so that the surface temperature of flammable building material not exceed 80°C. -
Page 7: System Parts
▀ System components Laddomat Laddomat or an equivalent product should always be installed between the boiler and accumulator tank. The Laddomat is described in detail on page 12. The Laddomat prevent the boiler from being overheated by sending the cold water from the accumulator to the boiler in case of a power failure. -
Page 8: System Parts
System components ▀ The valve kit The valve kit is fitted to the hot water circuit, and is installed to premix the water before it reaches the tap point. This means you avoid burns and the temperature can be easily adjusted. If it is not installed, mixers at tap points will deteriorate and break. -
Page 9: Environment
▀ Environment Surroundings When you heat with wood, you must fire up in a way that is gentle to the environment and your surroundings. It is important that you think of the people who live around you. Try to remember the following things below. -
Page 10: Component Placement
Component placement ▀ Front Back Inspection glass Drain cock Control switch Handle soot door Return pipe Incoming pipe Soot door Wing nut for detaching fan Smoke connection Air intake Splice connector fan Cover plate for soot door Damper motors (behind plate) Sensor boiler temp Handle loading compart. -
Page 11: Technical Data
▀ Technical data EXPLANATION 1210 1. FLOW ACCUMULATOR 1 1/4” 1260 2. RETURN ACCUMULATOR 1 1/4” 3. DRAIN COCK 1/2” TECHNICAL DATA Width 600 mm Depth incl. Flue elbow 1260 mm Height 1280 mm Weight 350 kg Maximum pressure 1,5 bar Flue tube (extra) 150x150x630 mm Smoke pipe diameter... -
Page 12: Function Laddomat
▀ Function Laddomat 21-60 1. Start-up when the boiler temperature is below 78°C, the cartridge has not opened, the beam for self-circulation is tight against the accumulator tank due to pump pressure. 2. Operational phase when the boiler temperature exceeds 78 °C, the cartridge opens and mixes cold water from the accu- mulator tank. -
Page 13: Sleeve Placement Accumulator Bbs
▀ Sleeve placement solar accumulator tank BBS 1889 1616 1534 1456 1274 1075 Effecta AB - Västra Rågdalsvägen 21 - 434 99 Kungsbacka - +46 (0)300 22320 - info@effecta.se... -
Page 14: First Firing
The first firing ▀ Remember that during the first firing the boiler can feel sluggish and tough to fire. This is because all the metal surfaces in the boiler are clean and cooled against the boiler water, the ceramics also has some moisture that needs to dry. -
Page 15: Menus
Menus ▀ Effecta Woody Lambda Flue 45°C Boiler 47°C A:start C:menu Starts the boiler Damper status. Indicates boiler temp. Damper status. Indicates flue Entry menu. gas temp. Menu for firing Showing carbon dioxide concentration, becomes active at a __.__ % flue temperature of 100°C. -
Page 16: Electrical Installation
▀ Electrical installation CONDENSER PELLET BURNER NOT STANDARD CONNECTION BLUE BLUE CONVERTER BLUE POTENTIOMETER BROWN ORANGE DAMPER PRIMARY YELLOW BROWN ORANGE DAMPER SECUNDARY YELLOW BLACK GREY BLUE LAMBDA SENSOR WHITE BROWN FLUEGAS GREEN BOILER TEMPERATURE GREEN Effecta AB - Västra Rågdalsvägen 21 - SE-434 99 Kungsbacka - +46 (0)300 22320 - info@effecta.se... -
Page 17: Cleaning And Service
Cleaning and service ▀ Cleaning interval 1. Loading compartment 40 hours firing. 2. Tubes 40 hours firing. 3. After burning chamber 15 hours firing. 4. Fan about 3 times a year. 5. Cleaning lambda sensor once per year. 6. Air distributor secondary air 40 hours firing. 7. -
Page 18: Cleaning
▀ Cleaning Secondary air In the columns where the flame is drawn down, there is a metal plate with holes (1.) Clean the plate after about 40 hours firing. Brush / scrape away the dust and ashes. If the holes become clogged combustion will... -
Page 19: Lever Cleaning
Lever cleaning ▀ As an extra option, you can equip the Lambda 35 with lever cleaning. Lever cleaning makes cleaning easier since you do not need to clean the tubes manually as often. Lever cleaning should be done frequently, preferably every time you fire up your boiler. This way, soot doesn't build up in the tubes and flue gas levels are kept low. -
Page 20: Adjusting The Doors
▀ Door adjustment There are a number of ways to adjust the hatch. In the pictures below you can see the hinge on the door. After some use, some adjustments maybe is needed so the gaskets do not draw extra air to the boiler. 1. -
Page 21: Rotate Door
Rotate the door ▀ As standard Effecta Lambda is delivered with door hinges on the right side. If you need to re- place the door hanging follow instructions below. Upper hatch 1. Start by loosening the two M12 bolts that hold the hatch in the against the frame. Remem- ber to have a shelter over the hatch to avoid scratches in the paint with continued work. -
Page 22: Connection Of Pipes
▀ Connection of pipes Effecta AB - Västra Rågdalsvägen 21 - SE-434 99 Kungsbacka - +46 (0)300 22320 - info@effecta.se... -
Page 23: Pellet Burning
Pellets burning ▀ If you have ordered an Effecta Lambda ready for pellets burning, remember that unless an Effecta Supra is fitted, the pellet burner must be a so-called forward burning type with an output below 25 Assembly Start by installing the pellets burner in the boiler by first installing the fitting plate (7.) with the four wing nuts. -
Page 24: Pellet Burning
Pellets burning ▀ Sensors The sensors for controlling start and stop of the pellets burner are installed in the accumulator tank. Sensor G5 is installed in (pos 14). Sensor G6 is installed in (pos. 8) on the accumulator tank as shown on (page 22). More information about the function of the sensors is available in the manual for the pellet burner. -
Page 25: Ceramic Tray
▀ Ceramics kit The ceramics tray is installed in the loading compartment. The purpose of the ceramics is to separate the different combustion zones in the loading compartment. It is important to monitor the tray since it is a wear part. In normal conditions, the ceramics tray will last for 6-8 years. When the tray is used up, combustion and efficiency deteriorate significantly. -
Page 26: Ceramic Replacement
Ceramics replacement ▀ Eventually it is time to replace the ceramics tray. In the pictures below you can see a cross- section of Effecta Lambda seen from above. Follow the instructions below for easy replacement. Installation is done via the loading compartment door. Start by breaking the old tray. -
Page 27: Air Damper Components
Air damper components ▀ To access the damper loosen the four screws holding the cover plate in front damper motors in place. Open the two doors to access the screws. Damper motor Set screw Stop pin Motor shaft Air damper Bracket motor Distance Air box... -
Page 28: Troubleshooting
Troubleshooting ▀ Problem Possible errors Action There is smoke emission during igni- The fan is turned off. Press ( start new firing ). tion. Smoke is seeping through the doors. A gasket is leaking. Adjust the doors. The fan will not start. An electronics malfunction. -
Page 29: Ce Marking
Declaration of conformity: Effecta Pannan AB Västra rågdalsvägen 21 SE-434 99 Kungsbacka The declaration refers to the responsibility of the product: Effecta Woody: Wood boiler Number: 02-756697-02 Directive: 89/336/EEC with supplements 92/31/EEC, 93/68/EEC (EMC) 73/23/EEC with the supplement 93/68/EEC (LVD) 97/23/EC (PED) Harmonised standards: SS-EN 60204-1 Electrical equipment for industrial ma-... - Page 30 Effecta AB - Västra Rågdalsvägen 21 - SE-434 99 Kungsbacka - +46 (0)300 22320 - info@effecta.se...
- Page 31 Effecta AB - Västra Rågdalsvägen 21 - 434 99 Kungsbacka - +46 (0)300 22320 - info@effecta.se...
- Page 32 Effecta AB - Västra Rågdalsvägen 21 - SE-434 99 Kungsbacka - +46 (0)300 22320 - info@effecta.se...
