SAFETY CONSIDERATIONS

Installing and servicing air-conditioning equipment can be
hazardous due to system pressure and electrical components.
Only trained and qualified service personnel should install or
service air-conditioning equipment.
Untrained personnel can perform basic maintenance, such as
cleaning and replacing filters. All other operations should be
performed by trained service personnel. When working on air
conditioning equipment, observe safety precautions in litera-
ture, tags, and labels attached to unit.
Follow all safety codes. Wear safety glasses and work gloves.
Use quenching cloth for brazing operations. Have fire extin-
guisher available. Read these instructions thoroughly. Con-
sult local building codes and the National Electrical Code
(NEC) for special installation requirements.
WARNING: Before installing or servicing system,
always turn off main power to system. There may be
more than one disconnect switch. Turn off accessory
heater power if applicable. Electrical shock can cause
serious personal injury.
installation, start-up and
service instructions
FAN COIL UNITS
Cancels: New
CAUTION: This system uses R-410A, which has
Page
higher pressures than R-22 and other refrigerants. No
other refrigerant may be used in this system. All
equipment must be designed to handle R-410A refrig-
erant. If unsure about equipment, consult the equip-
ment manufacturer.
These instructions cover the installation, start-up and service
of cooling only and heat pump duct-free systems.
I. STEP 1 - COMPLETE PRE-INSTALLATION CHECKS
A. Unpack Units (See Fig. 1)
Move the unit to final location. Remove unit from carton,
being careful not to damage service valves and grilles. See
Table 1A for installation materials included in shipment and
see Table 1B for field supplied materials needed to complete
the installation.
B. Inspect Shipment
File a claim with the shipping company if shipment is dam-
aged or incomplete. Check the unit nameplate to ensure unit
matches the job requirements.
C. Consider System Requirements
Consult local building codes and NEC for special installation
requirements. Use only designated indoor units with outdoor
units. See Tables 2 and 3.
Fig. 1 - 619ENF,ENQ Units
619ENF
619ENQ
Sizes 018-036
II 619E-18-4

GENERAL

INSTALLATION
4/1/06

Advertisement

Table of Contents
loading

Summary of Contents for Bryant 619ENF

  • Page 1: Table Of Contents

    WARNING: Before installing or servicing system, always turn off main power to system. There may be more than one disconnect switch. Turn off accessory heater power if applicable. Electrical shock can cause serious personal injury. Fig. 1 — 619ENF,ENQ Units...
  • Page 2: Installation

    5/14* For wireless remote control mounting bracket installation. Wireless Remote Control For wireless remote control installation. Mounting Bracket *619ENF01824, 619ENQ018,024: 5 619ENF,ENQ030,036: 14 Table 1B — Installation Materials — Field-Supplied NAME SPECIFICATIONS Liquid line: in. (619ENF,ENQ018-036) Connection Pipe (nominal capacity) Mixed Phase line: in.
  • Page 3 18,000 24,000 30,000 36,000 OPERATING WEIGHT (lb) MOISTURE REMOVAL RATE 5.4/5.2 7.9/7.9 8.8/9.2 13.0/12.8 (Pints/hr) (619ENF/ENQ) REFRIGERANT Type R-410A Control Device (Cooling) Accurator Piston at Outdoor Unit Control Device (Heating) Accurator Piston at Outdoor Unit System Charge Required (lb)* 10.5...
  • Page 4 619ENF01824 619ENF,ENQ 619ENQ018,024 030, 036 DIMENSIONS DIMENSIONS (in.) (in.) 42.5 57.5 11.6 13.4 619ENF,ENQ Fig. 2 — Unit Dimensions 4 in. 8 in. min. min. 4 in. min. 80 in. min. 619ENF,ENQ UNITS Fig. 3 — Unit Clearances —4—...
  • Page 5: Step 2 - Mount Unit

    II. STEP 2 — MOUNT UNIT 5 in. min. Before mounting the 619ENF,ENQ unit on the wall with a wall hanging bracket, consider how the unit will be connected to the refrigerant piping. The indoor unit can be connected in four ways. Refer to Fig. 4 for connection options.
  • Page 6 Outdoor side Drill at Slope 1/4 to 1/2 in. lower Indoor side Fig. 7 — Placement of Connection Piping Fig. 10 — Location of Piping, Hose and Wiring 3. Fix the bottom part of the unit to the wall hanging bracket by pushing it carefully until the two bracket Drain Cap hooks fit into the marked places at the base of the...
  • Page 7 Open the mixed phase valve for 3 seconds, then quickly shut it to check for possible leaks. Replace caps and check for leaks using a leak detector spe- cific for R-410A refrigerant. DIMENSION UNIT SIZE After the leak test, fully open the three-way valves. 619ENF01824 13.4 10.6...
  • Page 8: Step 4 - Make Electrical Connections

    Such operation would invalidate any applicable Bryant warranty. WARNING: Before performing service or mainte- nance, be sure main power switch is turned OFF and indoor blower and outdoor fan have stopped.
  • Page 9 Fig. 16 — 619ENF01824 Matched with 538ENF Typical Wiring Schematic —9—...
  • Page 10 Fig. 17 — 619ENQ018,024 Matched with 538QNF Typical Wiring Schematic —10—...
  • Page 11 Fig. 18 — 619ENF030,036 Matched with 538ENF Typical Wiring Schematic —11—...
  • Page 12 Fig. 19 — 619ENQ030,036 Matched with 538QNF Typical Wiring Schematic —12—...
  • Page 13: Start-Up

    Table 5 — 619ENF,ENQ Fan Coil Electrical Data VOLTAGE RANGE* POWER MIN WIRE UNIT SIZE V-PH-Hz Motor Power SIZE MOCP (Watts) 619ENF01824 208/230-1-60 0.38 0.48 619ENF030 208/230-1-60 0.38 0.48 619ENF036 208/230-1-60 0.44 0.55 619ENQ018 208/230-1-60 0.38 0.48 619ENQ024 208/230-1-60 0.38 0.48...
  • Page 14: Service

    NOTE: Do not install a suction-line filter drier in the mixed SERVICE phase line. WARNING: Before performing recommended III. REFRIGERANT CHARGING maintenance, be sure unit main power switch is turned off. Failure to do so may result in electrical shock or WARNING: To prevent personal injury, wear injury form rotating fan blade.
  • Page 15 Table 7 — Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Compressor and Fan of the Outdoor Unit not energized Check the main power connection. Unit Will Not Start Main switch is set to OFF Check and put it to ON position. Main switch fuses are blown Replace fuses.
  • Page 16 Copyright 2006 Bryant Heating & Cooling Systems Printed in U.S.A. CATALOG NO. 02-619E0001-SI...
