- Page 1 EXSOUND Pearl ll C User's Guide...
-
Page 2: Table Of Contents
• XBOX360 / XBOX L Voice Settings --------------------------------------------------- 08 ® ® --------------------------------------------------------- 09 • Pearl ll C Connects to XBOX Live ® • Pearl ll C Connects to PS3 ™ ----------------------------------------------------------------- 10 ® ------------------------------------------------------ 10 • PS3™ PlayStation Network Settings ------------------------------------------------------------------- 11 •... -
Page 3: Package Contents
Package Contents 1. One EXSOUND Pearl ll C Headset 2. One EXSOUND Pearl II C Breakaway Inline Controller Cable 3. One EXSOUND Pearl ll C Microphone 4. One EXSOUND Pearl ll C Audio Station 5. One USB Cable 6. One Optical Cable 7. - Page 4 Hardware Diagram A. EXSOUND Pearl II B. EXSOUND Pearl II C Headset C. EXSOUND Pearl II C Breakaway Inline Controller Cable A. EXSOUND Pearl II C Audio Station 1. Optical Input: Connect with Optical Output Devices, Like DVD, XBOX360 ®...
- Page 5 Headset by aligning two dots Secure the Microphone by Rotating it 90 degrees counterclockwise C. EXSOUND Pearl II C Breakaway Inline Controller Cable 20. Volume Up/Down 21.With Headset Amp and w/o Amp Selections (If Use Only Headset To Connect with PC Must be w/o Amp) 22.Microphone Mute/Un-mute...
-
Page 6: Product Operation & Led Indicator
Product Operation & LED Indicator Product Operation 1. PWR Button: Power ON/OFF Default is OFF while Power In, Press is ON, Press Again is OFF 2. VOL+ Button: Volume Up Switch 3. VOL- Button: Volume Down Switch 4. Dolby Headphone Button: First Press is Default Dolby Headphone with Movie Mode,then Dolby Headphone with Music Mode, then Dolby Pro Logic ll and Dolby Headphone are OFF, then Loop. - Page 7 1. Most of Gaming/Movie Titles Are DVD Format, and Encoded with Dolby Digital 5.1 Technology, Multi – Channels Sound. Need to Have Pearl ll C , with Dolby Digital 5.1 Decoder to Have Original Sound Play back. 2. Sound with Analog Interface, with 2 Channels, Maybe Different Format, Like Pro logic II with Wii and Lt Rt from other Devices , Pro Logic II with simulate these 2 Channels into 5.1 Channels.
-
Page 8: Pearl Ll C Connects To Xbox360
Pearl ll C Connects to XBOX360 ® 1. Connect Pearl II C Headset with Breakaway Inline Controller Cable 2. Plug the USB connector into the USB port of XBOX360 and the decoder box. ® 3. Connect the decoder box and XBOX360 ®... -
Page 9: Pearl Ll C Connects To Xbox Live
Pearl II C Connects to XBOX Live ® 1. Connect XBOX Live communication link cable (2.5mm plug to 3.5mm plug) to inline volume controller and ® XBOX360 controller ® Adjust Others Voice Volume by Turning the Voice Volume Control 2. Special Note : When you use XBOX Live communication function not allow recharge your controller ®... -
Page 10: Pearl Ll C Connects To Ps3
Pearl ll C Connects to PS3™ 1. Connect Pearl II C Headset with Breakaway Inline Controller Cable 2. Connect USB Communication cable to an USB port on PS3™ and the decoder box. 3. Connect the decoder box and PS3™ with Optical cable. -
Page 11: Pearl Ll C Connects To Dvd
l l l 1. Connect Pearl II C Headset with Breakaway Inline Controller Cable 2. Connect the USB connector into an USB port of USB output AC adapter device and decoder box. 3. Connect the decoder box and DVD Player with Optical cable. 4. -
Page 12: Pearl Ll C Connects To Pc
Pearl ll C Connects to PC 1. Connect Pearl II C Headset with Breakaway Inline Controller Cable 2. Connect the USB connector to an available USB port on your computer and the decoder box. You Can Select Your Source from Optical In or Analog In 3. -
Page 13: Pearl Ll C Headset Connects To Pc/Mp3
l l l A. Connect Pearl II C to PC with Breakaway Inline Controller Cable 1. Connect Pearl II C headset with Breakaway Inline Controller Cable. 2. Slide the “Amp / To PC” switch on the inline controller to “To PC “. 3. -
Page 14: Pearl Ll C Connects To Tv
Pearl ll C Connects to TV 1. Connect Pearl II C Headset with Breakaway Inline Controller Cable 2. Connect the USB connector to USB port of an USB AC adapter device and decoder box. 3. User needs to prepare one RCA plug *2 to 3.5 mm plug connection cable, Connect the RCA plug to TV and 3.5mm plug to analog input port of decoder box. -
Page 15: Pearl Ll C Connects To Wii
Pearl ll C Connects to Wii ™ 1. Connect Pearl II C Headset with Breakaway Inline Controller Cable 2. Connect the USB connector into an available USB port of Wii ™ and decoder box. 3. User needs to prepare one RCA jack *2 to 3.5 mm plug connection cable, Connect the RCA jacks to Wii ™ and 3.
