EXSOUND JerryFish Digital RF Wireless
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JerryFish Digital RF Wireless and is the answer not in the manual?

Questions and answers

Related Manuals for Exsound JerryFish Digital RF Wireless

Summary of Contents for Exsound JerryFish Digital RF Wireless

  • Page 1 EXSOUND JerryFish Digital RF Wireless User's Guide...

  • Page 2: Table Of Contents

    -------------------------------- 08 ® • JerryFish Digital RF Wireless Connects to XBOX Live ------------------------------ 09 ® • JerryFish Digital RF Wireless Connects to PS3 ™ --------------------------------------- 10 • PS3™ Audio Settings - - - - - - - - -------- - - -...

  • Page 3: Package Contents

    Package Contents 1. One EXSOUND JerryFish Digital RF Wireless Headset 2. One EXSOUND JerryFish Digital RF Wireless Microphone 3. One EXSOUND JerryFish Digital RF Transmitter 4. One EXSOUND JerryFish Digital RF Receiver 5. AA Battery*2 (Note: These Bundle Batteries Can Not be Re-Charged.) 6.

  • Page 4: Product Features / Hardware Diagram

    Product Features / Hardware Diagram Product Features EXSOUND JerryFish Digital RF wireless – Entry Digital RF Wireless Gaming Headset, with Best of Best Sound Quality to XBOX360 ® /PS3™ with Communication Function /PS3™ with Analog Interface ■ Ease to Use, Just Connect with XBOX360 ®...
  • Page 5 Connect & Remove Microphone with Secure the Microphone by Headset by aligning two dots Rotating it 90 degrees counterclockwise B. JerryFish Digital RF Wireless Fuction Key - Transmitter 1. Input Channel (RCA) 2. USB Port for Power 3. RF Pairing Button 4.

  • Page 6: Product Operation & Led Indicator

    7. Micro USB Port for Battery Re-Charge 8. Receiver Unit ON/OFF 9. RF Pairing Button 10. LED1: Pairing & Volume Level Status Indicator 11. LED2: Battery & Re-Charging Status Indicator 12. Battery Case Cover Product Operation & LED Indicator Product Operation & LED Indicator - Transmitter 1.
  • Page 7 (i) While RF Signal is Pairing, LED Flashed Slowly; RF Signal Paired then LED off. (ii) While Adjusting Volume, LED Flashed Quickly; While the Volume Reaches Max Level, the LED Would be Always On Till Stop Pressing the Volume Control; While the Volume Reaches Min Level, the LED Would be Off;...

  • Page 8: Jerryfish Digital Rf Wireless Connects To Xbox360

    ® 1. Plug the USB connector into the USB port of XBOX360 ® and the Transmitter. 2. Plug RCA Cable into RCA Input of Transmitter with XBOX360 ® Standard Audio Cable. 3. Plug round 6-pin plug (Male) from JerryFish headset into the Receiver. 4.

  • Page 9: Jerryfish Digital Rf Wireless Connects To Xbox Live

    JerryFish Digital RF Wireless Connects to XBOX Live ® 1. Connect XBOX Live communication link cable (2.5 mm plug to 3.5 mm plug) to the Receiver and XBOX360 ® ® controller Adjust Others Voice Volume by Turning the Volume Control.

  • Page 10: Jerryfish Digital Rf Wireless Connects To Ps3

    JerryFish Digital RF Wireless Connects to PS3™ 1. Connect USB cable to an USB port on PS3™ and the Transmitter. 2. Plug RCA Cable into RCA Input of Transmitter with PS3™ Standard Audio Cable. 3. Plug round 6-pin plug (Male) from JerryFish headset into the Receiver.

  • Page 11: Jerryfish Digital Rf Wireless Connects To Dvd

    Note : Please make sure the DVD Audio Output source setting have to selet to “Analog Output” JerryFish Digital RF Wireless Connects to PC 1. Connect the USB connector to an available USB port on your PC and the Transmitter.

  • Page 12: Jerryfish Digital Rf Wireless Connects To Tv

    JerryFish Digital RF Wireless Connects to TV 1. Connect the USB connector to USB port of an USB AC adapter device and Transmitter. 2. User needs to prepare one RCA*2 plug to RCA*2 plug connection cable, Connect the RCA plug to TV and the other side RCA plug to the input of Transmitter.

  • Page 13: J R E Y R F S I H D G I

    1. Connect the USB connector to USB port of an USB AC adapter device and Transmitter. . Connect the 3.5mm plug to iPhone/iPa d/iPod and the other side RCA plug to the input of Transmitter. the Receiver. Power on Transmitter/Receiver and start to RF pair. Important Information PlayStation, PlayStation 2, PlayStation 3, PS2, PS3 and the respective images/logos are registered trademarks of Sony Computer Entertainment Inc.
