Exsound SWORDFISH Manual

SWORDFISH Manual Table Of Contents
Package Contents
1
Safety Notice 2
Product Features 2
Hardware Diagram 3
Charging the Battery
5
6
Connect to PC/Laptop/Smartphone/Tablet/Media Devices
Mode Selections: Movie/Gaming or Music 7
8
Connect to XBOX ONETM
8
Connect to PS4TM
Important Information
9
Package Contents
1. One EXSOUND SWORDFISH Headset
2. One EXSOUND SWORDFISH Micro-USB charging cable
3. One EXSOUND SWORDFISH Soft Carry Bag
4. One Adaptor for Different Smartphone/Tablet Audio Interface
5. One Operation Manual
1
Safety Notice
Warning
Continued exposure to high volumes of noise in headsets can cause long-term hearing
damage. Your ears will adapt to loud volume levels over time and damage your hearing
even if you don't feel any discomfort. Maintain the volume at an adequate level is
important while using the headset. The louder the sound is, the less time it takes
to affect your hearing. It is recommended that before putting the headset on, turn the
volume down completely, then slowly increase it to a moderate and comfortable level.
Product Features
EXSOUND SWORDFISH – Dolby Pro Logic IIX, Dolby Headphone technolgies to
output virtual 7.1 channel surround sound for Gaming And Music Entertainment
Specific design to work on PS4, Xbox One, Smartphone, Tablet,
and Laptop with Dolby 7.1 surround sound for untimate
Gaming/Music/Movie experience with Movie/Gaming or Music mode selections
High-fidelity sound quality with crystal clear high & mid-range and booming bass
Standard 3.5mm AUX connection. Simply just plug in and play
Foldable design. Easy to carry and store with the included soft carry bag
Built-in microphone for on-the-move phone calls
Built-in battery for continuing 8-hours of music entertainment
Ergonomics design of breathable sponge covered with
smooth protein material ear cushion, provide extended-wear comfort experience
2
Hardware Diagram
A. EXSOUND SWORDFISH Headset
1
2
SWORDFISH
Built-in Microphone
6
3 4
7 8 9
5
10 11 12
13
14
3
Hardware Diagram
1. High quality & soft material headband
2. Easy to adjust to fit in head shape
3. Microphone On
4. Microphone Off
5. Charging Port
6. Power ON
7. Power Off
8. Dolby 7.1 Surround Sound On
9. Dolby 7.1 Surround Sound Off
10. Music Mode
11. Normal Mode
12. Movie/Gaming Mode
13. Volume Up
14. Volume Down
B. Folding EXSOUND SWORDFISH
To carry SWORDFISH with minimal space requirement,
you can fold it in 2 different ways:
To fold the headset as flat as possible: To fold the headset as compact as possible:
Turn the ear cup 90∘ as illustrated Fold the ear cups inward as illustrated
and put it into the carry bag and put it into the carry bag
4
Charging the Battery
1. To charge the SwordFish, plug in the USB end to any power source with
USB port such as power adapter or computer
2. Plug the micro-USB end of the cable into the charging port on your SwordFish
3. LED indicator will display blue light while charging,
and will shut off once charging is complete.
1
2
5
