Visonic AMBER SELECT Quick Start Manual

AMBER SELECT /
AMBER SELECT
Setting Up Your System
To set up your system, follow the steps below. For
more detailed information,
SELECT / AMBER SELECT
Select a central location in your home for the
AMBER SELECT / AMBER SELECT
spend most of your time. The AMBER SELECT /
X
AMBER SELECT can be placed on a table, desk,
or counter. It also can be mounted on the wall.
After you complete steps 1 and 2, your AMBER
SELECT / AMBER SELECT
your Central station to guide you through the rest of
the setup.
Note: Certain remote areas of your residence may
lie outside the reception range of the AMBER
SELECT / AMBER SELECT
not being able to receive transmissions directly. In
this case, a Repeater (MCX-600) can be used to
increase the AMBER SELECT / AMBER SELECT
reception range.
Contact a Visonic representative for further details.
1. Connect the Base Unit to your
Telephone Line:
Connect the wide end (RJ-45) of the phone cord to
the "Wall Jack" on your AMBER SELECT / AMBER
X
SELECT . Plug the narrow end (RJ-11) of that
phone cord into the phone jack on your wall.
Note: Be aware of other phone line services
such as DSL. If DSL service is present on the
phone line, you must install a filter. For more
information regarding the DSL filter, contact the
service provider.
D-301439
X
see the AMBER
X
User Guide.
X
where you
X
will automatically call
X
, resulting in the unit
INSERT THE SAFETY CATCH TAB HORIZONTALLY AS SHOWN.
TURN THE LEFT SIDE OF THE CATCH COUNTER-CLOCKWISE
UNITL IT FACES THE SCREW HOLE AND THEN FASTEN THE
SAFETY CATCH WITH THE SCREW
SCREW
HOLE
Note: The safety catch is optional, can be
purchased upon request.
X
CONNECT THE
ADAPTER
INTO A NEARBY
ELECTRICAL
OUTLET
WARNING!
DO NOT USE AN OUTLET CONTROLLED BY A
WALL SWITCH.
When electrical power is supplied to the Base Unit,
the green light on the front panel illuminates.
2. The AMBER SELECT / AMBER
SELECT is now Connecting you to
X
the Central Station:
After installation, a Monitoring Center representative
will begin speaking to you.
When your Monitoring Center representative
answers, you can hear the representative talking
to you through the AMBER SELECT / AMBER
X
SELECT Unit. You can talk to the representative
by speaking normally. You do not need to use the
phone.
The Monitoring Center representative will guide you
through the rest of the system setup.

Quick Start Guide

Phone Line RS232 X10
(AMBER
SELECT
only)
1
