Product:
Dryer
Date:
11.1.2002
Reference:
N-Å Carlsson
ASKO Cylinda's range of tumble dryers was modified during the autumn of 2001, and a brief
overview of the modifications that were made is given below.
Further information can be obtained in the service manuals given below.
New type
Replaces old type
TD11
TD11
TD22
TD22
TD30
NEW
TD40
NEW
TD33A
TD33
TD44A
TD44
Service manual
Overview of new/modified types of
tumble dryers introduced to the
market in 2001
Main differences
New panel graphic.
New panel graphic.
Air vent. Electronic control with knob and
7-segment LED display
Condensor. Electronic control with knob and
7-segment LED display.
New control card. New menu logic.
Among other things, 1-24 hour delayed start.
New panel graphic. Shop program as shown in the display.
See TD33A
Type: TD30 TD40
Group:
22
Page:
Product info
E
E
F
F
1(9)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asko TD30
Summary of Contents for Asko TD30
- Page 1 N-Å Carlsson Page: 1(9) ASKO Cylinda’s range of tumble dryers was modified during the autumn of 2001, and a brief overview of the modifications that were made is given below. Further information can be obtained in the service manuals given below.
- Page 2 This service manual is intended as a supplement to the T700-series service manual. Example of TD30/40 Panel General Mechanically the TD30/40 is based on TD33/44 (T760/T780), except for the panel and control unit. For more information, see the service manual for the T700 series. TD30...
-
Page 3: Display Indications
Handling 1. Sort the textiles. 2. Turn on the main switch, 3. Open the door, load the textiles, then close the door again. 4. Select program with the knob. The programs you may choose from are: 1. Extra dry 2. Dry 3. -
Page 4: Options And Settings
Options and settings Settings are shown on the display or on an LED next to the appropriate button. The machine remembers the settings and options you make for each program and starts from them next time you select the program concerned. Anti-crease You may choose to have the option active for 1-3 hours. -
Page 5: Error Messages
Error messages If an error or fault occurs in the course of the program this is indicated on the display. N.B. To reset the error message the main switch must be turned off. T h e d i s p l a y Description Explanation / proposed measure shows... -
Page 6: Drying Temperature
Consumption values TD30 The following conditions apply to the consumption values indicated below: Temperature of the supply air: 20 °C. Moisture content of the supply air: 65 %. Drying temperature: Normal ( ), Låg ( ). Element power: 2620 W (2500 W, USA) Before tumble drying, cotton textiles are spun at 800 and 1600 rpm (long spin). - Page 7 Consumption values TD40 The following conditions apply to the consumption values indicated below: Temperature of the supply air: 20 °C. Moisture content of the supply air: 65 %. Drying temperature: Normal ( ), Låg ( ). Element power: 2500 W Before tumble drying, cotton textiles are spun at 800 and 1600 rpm (long spin).
- Page 8 Reprogramming display and button functions: S1 S2 S4 S5 Machine type TD30/40 No program selected. Program in 0 position Change power to obtain “right” time indication on TD40 5 x Start + 5 x S1 (selection of time in time program).
- Page 9 COMPONENTS AND MEASURED VALUES MOTOR INDICATING LAMP Art. no. 80618 24 (50 Hz) 80 070 73 EU Art. no. Winding resistance Current: 1.68 mA, 230 V, 509 Hz Cable colour white-blue: 24.5 Ω Cable colour white-red: 26.5 Ω 80 604 78 USA Art.
- Page 10 Art. no. 80 618 55 The moisture sensor is used to control the drying process. During operation the sensor TD30/40 (Small display) LED must have an output signal of between 1 – 16 Art. no. 80 642 60 ASKO m VDC.
