Behringer Digital Delay DD400 Quick Manual

Thank you for showing your confidence in us by purchasing the BEHRINGER DIGITAL
DELAY DD400. This ultimate effects pedal is designed to deliver 24-bit high-resolution stereo
delay sounds comparable to state-of-the-art studio processors. Thanks to its parameter
controls, you’ll have plenty of cool sounds at your disposal to handle every situation.
The delay effect creates a delay of the input signal with various repetitions. Different
tempo settings allow interesting delay effects.
The LEVEL control adjusts the output level.
The FEEDBACK (Feedback) control adjusts the amount of signal repetitions.
The TIME (Delay Time) control adjusts the exact delay time.Depending on the MODE
control position you can adjust it around 200 ms, 500 ms or 1300 ms. The delay time
describes how fast the signal repetitions will follow after the original signal.
With the MODE control you can chose between three different delay time ranges
around 200 ms, 500 ms or 1300 ms with either mono (M) or stereo (S) delay. The
exact delay time can be adjusted by the TIME control. In position HOLD the signal
will be repeated constantly.
The ON/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator.
Use the footswitch to activate/deactivate the effect.
Use this 1/4" TS IN connector to plug in the instrument cable.
The two 1/4" TS connectors OUT A and OUT B send the signal to your amp. Use both
connectors if you want to achieve full stereo delay effect. For mono use just plug in OUT A.
Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery, press the hinges with a ballpen and remove the pedal cover. Be
careful not to scratch the unit.
DIGITAL DELAY DD400
1. CONTROLS
Top view
