Preparation
1.
Important! Your Internet-connection will be activated at the chosen specific date that
has been communicated to you. You will also receive a text message (SMS) informing
you that your connection is ready: you can then start with your installation.
2.
Important! Remove the devices and cables you have been using up until now
(in order to always use the latest technology):
router & power supply unit
Simple disposal: you can send your old devices and cables back to Swisscom by post, at
no cost or bring it to the nearest Swisscom Shop. To do so, please use the return sticker
enclosed with the delivery notice.
3.
Unplug all telephone and fax devices.
4.
What do your telephone sockets look like?
a) b)
or
4.1 Plug a new microfilter into a telephone socket.
a)
microfilter
Important! a) b) c) For every telephone socket you wish to use in your home you must
plug in a new microfilter. You can purchase additional microfilters and adapters in your
Swisscom Shop.
4.2 For customers with a wireline phone:
plug your wireline phone device
into the microfilter.
Exception! d) For this socket you don't need a
microfilter. Your splitter and the illustrated socket
have the same function for all the telephone sockets
in your home.
8
all microfilters DSL cable (router –
telephone socket)
c) d)
or or
b) c)
d)
1 2
3
4 5
6
7 8
9
* 0
# telephone

Router setup

5.
Connect your new router as shown in the
5.1 DSL cable
5.2 Ethernet cable
5.3 Power supply unit
6.
Switch your router on. The «power» light
7.
Please wait until the following router lights are on and white.
Activate your Internet
8.
Restart your computer.
9.
Before you can start surfing the net, you need to register.
Start your browser: Internet Explorer
registration page will automatically appear in your browser window
(www.swisscom.ch).
Please fill in all the required information step by step.
10.
remove
You have now successfully configured your Internet.
adapter
Note: If you have Swisscom TV, please also restart your TV-Box (switch on the back of
your TV-Box if available, else unplug power cable).

WLAN setup

Please follow the enclosed instructions to connect your computer to your WLAN
network.
DSL
splitter
overview illustration (p. 12–13)
Connect your router to the microfilter.
Connect your router to a computer.
Connect your router to the electrical socket.
goes on.
up to 15 min.
, Firefox , Safari
«Did you know? Your router has WPS!
For more information, please go to www.swisscom.ch/wps.»
with:
etc. The DSL
