POWER SUPPLY:

The laser tool requires 2 type AA 1.5 volt batteries to operate
(not included in packaging).

INSTALLING BATTERIES:

• Open battery door at base of tool.
• Insert 2 type AA 1.5 volt batteries as indicated in battery compartment
for correct polarity.
• Close battery door.
HOW TO USE YOUR STRAIT-LINE
• Remove safety insert from base of unit, prior to use to allow for push
pins to operate.
• Determine and measure where laser line will be projected.
• Position tool on surface on which line needs to be projected.
• For best results position the tool to project the line from right to
left or bottom to top. The use of the unit from left to right and/or
top to bottom will not garantee the same level of precision or
accuracy.
Page 5
® LASER LEVEL
For floor project:
• Simply lay tool on floor.
• Measure for position of laser line.
• Align front notch at base of tool with measurement marks.
• Turn laser beam on by opening lens cover in front of tool
(DO NOT stare directly at laser beam).
• Align flooring material to laser beam projected on floor surface.
For wall project (drywall or soft wood only):
• Measure for height of beam.
• Align front notch at base of tool with measurement marks.
• Push front tab to anchor metal pin into wall.
• Turn laser beam on by opening lens cover in front of tool
(DO NOT stare directly at laser beam).
• Verify that line is aligned with measurement marks.
• Push back tab to anchor metal pin into wall.
• Verify that tool is secure.
• Align project to laser beam projected on wall surface.
Page 6
