This tool is designed to create a straight line on the surface
on which the tool is placed; any reflection of the line on other surfaces,
such as a return wall, should not be used as a reference.
TECHNICAL SPECIFICATIONS:
Recommended use:
Indoor
Length of laser line:
Up to 30 ft (10 meters)
Laser diode type:
Red laser diode 635 nm
Laser class:
US version * Class IIIA
EU version * Class IIIR
Operational area:
Up to 30 feet (10 meters) of visible
light, indoors.
Power supply:
2 type AA – 1.5 volt batteries
Battery life:
40 hours of continuous use with alkaline
batteries
Operating temperature:
30°F to 104°F (-1°C to 40°C)
Dimensions:
4 5/8" x 1 5/8" x 3" (120mm x 42mm x 78mm)
Weight:
6.3 oz (180 g) without batteries
Accuracy: +/- 1/2" at 30ft (+/- 13.0 mm at 10 meters)
Page 3
TOOL COMPONENTS
Level vials
Laser lens
cover
Push
tab
Alignment
notch
Recessed
holding area
Battery door
Base
Push pins
