- Page 1 USER’S MANUAL POWER POWER SUBWOOFERS XV30 XS30 XV15 XS15...
- Page 2 AVIS: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE FUSE AND RATING. The lightning fl ash with arrowhead symbol is intended to alert the user to the presence of uninsulated “danger- ous voltage” within the product’s enclosure that may be of suffi...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read Instructions - All safety and operating instructions should be read before the subwoofer is operated. Retain Instructions - The safety and operating instructions should be retained for future reference. Heed Warnings - Adhere to all warnings on the subwoofer and in the operating instruc- tions. - Page 4 We are POWER POWER confi dent that the Power Sound Audio subwoofer will meet and possibly exceed your expectations. WARNING! To prevent fi re or shock hazard, do not expose this equipment to rain or moisture.
-
Page 5: Unpacking
Unpacking Unpacking Process (XS15, XV15, & XS30 ONLY) 1. Inspect the shipping box for any damage. If you notice any damage please contact us at support@powersoundaudio.com. 2. With assistance, place the subwoofer upside down, so the UP arrows are pointing at the ground. 3. -
Page 6: Placement
Placement Proper placement of your new Power Sound Audio subwoofer is very important. Bass frequencies are non-directional, meaning the human ear cannot locate a properly functioning subwoofer in a typical home theater environment. While there are “rules of thumb” regarding placement options, every room is a little differ- ent. - Page 7 Corner placement away from large opening Nearfi eld placement Multiple subwoofer placement Option 1 (collocated) Option 2...
-
Page 8: Installation
Installation Your subwoofer was designed for easy installation in a typical home theater environment. Please read all the installation instructions to properly optimize your sub- woofer. WARNING - Always be sure the power is OFF to any audio component before connecting or disconnecting any wires or cables. - Page 9 AMPLIFIER CONNECTIONS AND CONTROLS POWER SELECTOR SWITCH OFF = The subwoofer amplifi er is powered down. AUTO = Automatically powers up the subwoofer amplifer when a signal is sent from your receiver or processor. If a signal is not present, the subwoofer amplifi er is put into stand-by mode. The subwoofer amplifi...
-
Page 10: Connecting Your Subwoofer
(RCA) on the rear panel of your receiver/processor to the LEFT/LFE input jack on the subwoofer amplifi er. If you have a two channel stereo system please contact Power Sound Audio to discuss the best option to connect your new subwoofer. - Page 11 SETUP PROCEDURES RECEIVER/PROCESSOR BASS MANAGEMENT OPTIONS Once the subwoofer is connected to your receiver or processor you should enter the “set up” menu and set all of your speakers to “small”. If they give you options for the crossover frequency e.g., 40hz, 60hz, 80hz, 100hz, start with 80hz.
- Page 12 SETUP PROCEDURES PHASE SETTING The PHASE control is used to properly blend the main speakers with the subwoofer through the crossover region. The goal is to adjust the PHASE control so the subwoofer driver moves in unison with the main speaker drivers through the crossover region.
-
Page 13: Warranty
Warranty Power Sound Audio warrants its products to be free from original manufacturing defects in materials and workmanship for a period of 5 years from the original date of purchase. The warranty applies to the product and not the end user. If...
