Summary of Contents for Power Sound Audio T18HT
- Page 1 USER’S MANUAL T18HT...
- Page 2 AVIS: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE FUSE AND RATING. The lightning fl ash with arrowhead symbol is intended to alert the user to the presence of uninsulated “danger- ous voltage” within the product’s enclosure that may be of suffi...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read Instructions - All safety and operating instructions should be read before the subwoofer is operated. Retain Instructions - The safety and operating instructions should be retained for future reference. Heed Warnings - Adhere to all warnings on the subwoofer and in the operating instruc- tions. - Page 4 We are very excited to welcome you to the Power Sound Au- dio family. We would like to take this time to congratulate you on your purchase of a T18HT subwoofer. We are confi dent that the Power Sound Audio subwoofer will meet and possi- bly exceed your expectations.
-
Page 5: Unpacking
Unpacking Unpacking Process 1. Inspect the shipping box for any damage. If you notice any damage please contact us at support@powersoundaudio.com. 2. Carefully cut the straps that secure the subwoofer to the pallet. 3. Open the top of the shipping box. You will see a box that con- tains the grills, and two spacers. -
Page 6: Placement
Placement Proper placement of your new Power Sound Audio subwoofer is very important. Bass frequencies are non-directional, meaning the human ear cannot locate a properly functioning subwoofer in a typical home theater environment. While there are “rules of thumb” regarding placement options, every room is a little diff er- ent. - Page 7 Corner placement away from large opening T18HT Nearfi eld placement T18HT Multiple subwoofer placement Option 1 (collocated) T18HT T18HT T18HT Option 2 T18HT...
-
Page 8: Installation
Installation Your subwoofer was designed for easy installation in a typical home theater environment. Please read all the installation instructions to properly optimize your sub- woofer. WARNING - Always be sure the power is OFF to any audio component before connecting or disconnecting any wires or cables. - Page 10 AMPLIFIER CONNECTIONS AND CONTROLS POWER SELECTOR SWITCH OFF/12V = The subwoofer amplifi er is OFF and can only be activated if a 12V source is con- nected to the 12V trigger. AUTO = Automatically activates the subwoofer amplifer when a signal is sent from your receiver or processor.
-
Page 11: Connecting Your Subwoofer
(RCA) on the rear panel of your receiver/processor to the LEFT/LFE INPUT (RCA) on the subwoofer amplifi er. If you have a two channel stereo system please contact Power Sound Audio to discuss the best option to connect your new subwoofer. - Page 12 SETUP PROCEDURES RECEIVER/PROCESSOR BASS MANAGEMENT OPTIONS Once the subwoofer is connected to your receiver or processor you should enter the “set up” menu and set all of your speakers to “small”. If they give you options for the crossover frequency e.g., 40hz, 60hz, 80hz, 100hz, start with 80hz.
- Page 13 SETUP PROCEDURES DELAY SETTING The DELAY control is used to properly blend the main speakers with the subwoofer through the crossover region. The goal is to adjust the DELAY control so the subwoofer driver moves in unison with the main speaker drivers through the crossover region.
-
Page 14: Warranty
Warranty Power Sound Audio warrants its products to be free from original manufacturing defects in materials and workmanship for a period of 5 years from the original date of purchase. The warranty applies to the product and not the end user. If...
