Viewsonic Corporation - ViewSonic VA1930wm-1 Service Manual

ViewSonic Model Number: VS11354
Rev: 1a
Serial No. Prefix: QFP
Item ViewSonic P/N
1 P-00008167 506040009710R
2 P-00008168 506040009700R
3 N/A 506039000100R
4 N/A 506037005900R
5 CB-00008002 453030300120R
6 A-00006679 453070800250R
7 CB-00008009 453010100150R
8 N/A 506431000300R
9 N/A 506431003100R
10 N/A 506440002300R
11 N/A 506440002400R
12 N/A 506250012200R
13 N/A 506390000600R
14 N/A 506390500100R
15 N/A 506390210400R
16 N/A 506440002600R
17 N/A 506391000030R
18 N/A 506520700100R
19 P-00008169 506020012310R
20 P-00008170 506120301700R
21 N/A 506150007200R
22 N/A 506039003600R
23 A-00008063 703000003910R
24 N/A 714078061101R
25 N/A 501030204400R
26 N/A 501060200500R
27 C-00008182 501020209600R
28 N/A 509116608100R
29 N/A 509112306100R
30 N/A 503040000310R
31 E-00008012 618100101500R
32 N/A 509112306100R
33 C-00008180 714050007400R
34 N/A 506430300003R
35 N/A 501020209400R
36 C-00008181 714030007410R
37 N/A 501010207710R
38 N/A 501030204300R
39 N/A 506102000400R
40 N/A 506102000300R
41 N/A 501120104400R
42 PL-00008045 714010008600R
43 N/A 714088061100R
44 N/A 502090304100R
45 HW-00005269 509146305300R
46 HW-00005270 509000000700R
47 N/A 506380001200R
48 B-00008165 790691302600R
49 B-00008023 790691401600R
50 B-00008025 790682201000R
51 B-00008024 790691501000R
52 E-00008016 631102090600R
53 N/A 631102090610R
54 N/A 631102090720R
55 CB-00008010 430300400110R
56 CB-00008013 430303000600R
57 CB-00008011 430300800710R
58 N/A 505040503400R
59 N/A 509146304100R
60 N/A 505040204000R

ViewSonic Corporation

BOM LIST (VA1930wm-1)
Ref. P/N
CUSHION,EPS-R, LE1945
CUSHION,EPS-L, LE1945
CORNER PAPER,1000x50x50xT5mm
CARDBOARD,COVER,L1160xW1150xH120mm,LE194
CABLE,AUDIO 1P 6FT BLACK/GREEN CP03B06P0
PWR CORD 10A/125V BLK 6FT UL/CSA,SVT 18x
CABLE,D-SUB 15P MALE 6FT BLACK,SZ4120955
FILM,PE 500mmx900M ROHS
FILM,PROTECTION,UNPRINTED,430x280x0.1mm,
LABEL,BLANK,76.2x76.2mm,LE1709(UPC)
LABEL,BLANK,50x25mm,LE1709(S/N)
LABEL,AGENCY,LE1945(VA1930wm)
LABEL,HI-POT PASS, LE1709
LABEL,ENERGY STAR, LE1709
LABEL,CARTON(5ms),L89xW58 LE1941
LABEL,BLANK,210x65mm,LE1709(PALLET)
LABEL,POP,FOR BEZEL, LE1945
FLYER,LCDTV,LE1945(VA1930wm)
CARTON,VIEWSONIC(VA1930wm), LE1945
BAG,EPE+PE,L620xW510xT0.6mm, LE1925
PALLET,L1140xW1130xH120mm,LE1945
CORNER PAPER,1980x50x50xT5mm, LP1701
KIT,ACCESSORY,LE1945(VA1930wm)
ASSY,FINAL(B,V0/G1&2&3),W/SPK,US,LE1945-
BUTTON,FUNCTION KEY, LE1941
HOLDER,KEY PAD, LE1941
COVER,HINGE(B), LE1945
SCREW,P,CROSS,M4*8,Zn,ROHS
SCREW,P,CROSS,T.T-3*6,ZnROHS
RUBBER,COVER(B), LE1534
SPEAKER 1.5W 16Ω 350mm,R/B,W/CASE,X3516
SCREW,P,CROSS,T.T-3*6,ZnROHS
ASSY,BACK COVER, LE1945
FILM,PET,L115xW30xT0.05mm, LE1741
COVER,BACK(B),W/DVI, LE1941
ASSY,BEZEL, ,NO SILKSCREEN LE1945
BEZEL,FRONT,NO SILKSCREEN,LE1945
BUTTON,POWER KEY, LE1941
LOGO PLATE,VIEWSONIC, LE1709(THREE BIRDS
LOGO PLATE,VIEWSONIC, LE1709
LENS, LE1941
ASSY,STAND LE1945
ASSY,PANEL(V0/G1&2),W/SPK,LE1945-642
CHASSIS,W/DVI, LE1941
SCREW,PW,CROSS,W/WAS,M3*5,NI
BOLT,#4-40x11.8,Ni FOR D-SUB/DVI CONN.RO
TAPE,MYLAR,66000x20xT0.05
PCBA,I/F BOARD, LE1945-642
PCBA,P/I BOARD, LE1941-642
PCBA,LED BOARD, LE1941
PCBA,KEYPAD BOARD, LE1941
LCD PANEL 19" MT190AW01-V0-G1,AM19000040
LCD PANEL 19" MT190AW01-V0-G3,AM19000040
LCD PANEL 19" MT190AW01-V0-G2,AM19000040
HRN ASS'Y 4P 240mm UL1571#28,RoHS
HRN LVDS FFC 30P 160mm,RoHS
HRN ASS'Y 4Px2 to 8P,270mm UL1571#28,RoH
INSULATOR,PP,10x15x10X0.3mm,GLUE(3M), LE
SCREW,P,CROSS W/WAS,M3*4,Zn ROHS
INSULATOR,MYLAR,L370xW6xT0.3mm,LE1909
