6 FRONT PANEL CONTROLS AND INDICATORS
Front Panel Hardware Controls
Power Switch (Front Head)
Power LED (Front Head)
Front Panel Controls (Head)
[ ] [ 1 ] [ 2 ] [▲] [▼]
Reaction Time
Short Cuts Function from the button(s)
[1]
[2]
[▼]
[▲]
[▼]+ [▲]
[1] + [2]
[1] + [▼] + [▲]
[1] + [▼]
[1] + [▲]
[1] + [▼] + [2]
[▲]+ [ ] + Main Power On
No signal + [ ] + [2]
+ Main Power on
Signal + [2] + [ ] + Main Power
On
Remark : All the short cuts function are only available while OSD off
ViewSonic Corporation
Power Control, soft Power Switch.
Green – ON
Orange – Active Off
Dark = Soft Power Switch OFF
[ X] Mute
[ ] Power
[ 1 ] Button 1
[ 2 ] Button 2
[▲] Up arrow button
[▼] Down arrow button
Note: Power Button, Button 1 and Button 2 must be
one-shot logic operation. (i.e. there should be no
cycling)
OSD must fully appear within 0.5s after pushing Button
1
Main Menu
Input toggle (Analog or Digital; refer to Appendix D)
Brightness adjust
Contrast adjust
recall both of Contrast and Brightness to default
toggle 720x400 and 640x400 mode when input 720x400 or 640x400
mode
White Balance. (Not shown on user's guide)
Power Lock
OSD Lock
Disable Theft Defence function
All reset
Burning mode
Factory Mode
8
