5. Adjustment Procedure

1.
Key Function Description
CONTROL KEY
[AUTO] [2]
[MENU] [1]
[▼] [▲]
[POWER]
2.
Hot Key Operation
Item
[▲] + [▼]
[1] +[2]
[1] + [▼] + [▲]
(keep pushing 5 sec)
[1] + [▼]
[1] + [▲]
[▼] + [▲]+ [ ]
Remark: All the function above are only available while OSD off
3.
OSD Control
3.1 OSD table
Layer 1
Auto Image Adjust
Contrast/Brightness
Audio
Color Adjust
ViewSonic Corporation
By pressing [AUTO] key, "Auto Image Adjust" is performed
By pressing [MENU] key, Main menu display
A. When "MENU OSD" display, press these keys to change the contents of an
adjustment item, or change an adjustment value
B. When "MENU OSD" is un-display, press these keys to change brightness and
contrast
Power on or power off the monitor
Hot Key Function
Function Detail
Recall Contrast or Brightness while in the Contrast or Brightness adjustment;
Recall both Contrast and Brightness when the OSD is not open
Toggle 720x400 and 640x400 mode when input 720x400 or 640x400 mode
White Balance (Not shown on user's guide)
Power Lock
OSD Lock
Enter Factory Mode
Contrast (+ / -)
Brightness (+ / -)
Volume
Mute
sRGB
9300K
7500K
6500K
5400K
User Color
KEYS FUNCTION
Layer 2
*3,4
*3,4
Volume (+ / -)
On/Off
Red (+ / -)
Green (+ / -)
Confidential - Do Not Copy
28
Layer 3
VA1930wm-1
