Klipsch R-1650-C Specifications

6.5" In-Ceiling Speaker
Perfect for those who want excellent
performance, reliability and durability at
an affordable price, the R-1650-C brings
dynamic acoustic performance to both
home and commercial environments.
The R-1650-C employs a 6.5-inch
polymer-cone woofer and a large motor
structure for high sensitivity. A coaxially
mounted 1-inch polymer-dome tweeter
distributes smooth, clear highs over a
wide area.
The speaker's mounting system makes
installation a breeze, while its paintable
aluminum grille provides added rust
protection in moisture-prone areas such
as bathrooms, kitchens and saunas.
While the R-1650-C will fit into our latest
IK-650-C installation kit, it can also be
used in conjunction with the ME-650-C
fire-rated enclosure.
R-1650-C
• Good sensitivity and power handling
• Paintable to match ceiling
• Packaged individually
S p e c i f i c a t i o n S
frequency response
power handling
sensitivity
nominal impedance
drive components
dimensions
cutout dimensions
installation kit
weight
accessories
built from
All specifications are subject to change without notice. ©2007
57Hz-20kHz +/- 3dB
35 watts (140 watts peak)
91dB @ 2.83V/1 meter
8 ohms compatible
Two-way system using one 1"
(2.5cm) polymer dome, tweeter
and one 6.5" (16.5cm) poly woofer
9.5" (24.1cm)
8.3" (21cm)
IK-650-C (sold separately)
5.1 lbs (2.3 kg)
ME-650-C fire-rated
enclosure (sold separately)
2006
www.klipsch.com
1-800-KLIPSCH
