- Page 1 Dynamic Cooking Systems, Inc. ISLAND VENT HOOD Care and Use Installation Instructions Models: ■ DCS-IVH-48 ■ DCS-IVH-36...
- Page 2 Message T o Ou r Custome rs Thank you for selecting this DCS Professional Island Vent Hood. Because of this appliance’s unique features we have developed this Installation and Use Guide. It contains valuable information on how to properly operate and maintain your new appliance for years of safe and enjoyable use.
-
Page 3: Table Of Contents
T able of Contents IMPORTANT SAFETY INSTRUCTIONS ..........FEATURES . -
Page 4: Important Safety Instructions
Impo rtant Safety Inst ructions WARNING: To reduce the risk of a range top grease fire: A) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oil slowly on low or medium settings. B) Always turn hood “ON”... -
Page 5: Features
Featu res ISLAND VENT HOODS DCS-IVH-48 & DCS-IVH-36 The DCS Island Vent Hood Models: DCS-IVH-48 , DCS-IVH-36, have been designed with the ultimate in household convenience in mind. Features include a high capacity, variable speed blower with speed controller, commercial style dishwasher-safe filters, easy to clean inside grease trays and four halogen lights with Hi/Low light switch. -
Page 6: Planning The Installation
Planning the Installation BACKDRAFT DAMPER We recommend that a backdraft damper be used in all Vent Hood installations. Cold weather instal- lations necessitate the use of a backdraft damper to minimize the flow of cold air into the room. A non-metallic thermal break should also be installed to minimize conduction of outside temperatures through the ductwork. -
Page 7: Specifications
VENT HOOD DIMENSIONS DCS-IVH-48 DCS-IVH-48 12" 30" 12" 16" 34 5/8" 52 5/8" venting specs 4"x18" rectangular DCS-IVH-36 DCS-IVH-36 TOP VIEW of DCS-IVH-48 12" 16" 18" 34 5/8" FRONT VIEW SIDE VIEW 12" venting specs 7" Ø TOP VIEW of DCS-IVH-36... -
Page 8: Site Preparation And Installation Guidelines
1 1/2” by 3 1/2“ wood cut to fit the installation as shown in the following pages.The soffit mounting to the top of the Island Vent Hood will be 10 7/8“ in length for the DCS-IVH-48 and 10 3/4“... -
Page 9: Soffit Installation
Soffit Installation SOFFIT FOR DCS-IVH-36 ISLAND VENT HOOD The dimensions given are for a 1/2 inch drywall. 1) Create a soffit structure and attach the soffit brackets as in figure 1. Refer to the installation guidelines on Page 7. 2) Attach the soffit support bars as shown in figure 2. 3) After securing the soffit structure adequately to the ceiling joist, attach the Island Vent Hood with the mounting screws provided, figure 3. - Page 10 Soffit Installation SOFFIT FOR DCS-IVH-48 ISLAND VENT HOOD The dimensions given are for a 1/2 inch drywall duct cover. 1) Create a soffit structure and attach the soffit brackets as illustrated in figure 1. Refer to the installation guidelines on Page 7.
- Page 11 Soffit Installation DIAGRAMS FOR DCS-IVH-48 ISLAND VENT HOOD The dimensions given are for a 1/2 inch drywall duct cover. Figure 6 below illustrates a finished soffit structure for the DCS-IVH-48 Refer to page 7 on finishing the installation. FIG.6B Support Bars...
-
Page 12: Ducting Information
• Transitions are required from rectangular to round ducting. (see transitions as shown below) • Duct tape may be used at ducting joints. DCS-IVH-48 REQUIREMENTS • DCS recommends the use of 10” round ducting which provides 78.6 In. of surface area. -
Page 13: Care And Use
Ca re And Use CONTROLS We recommend you turn your hood on before you begin cooking to establish fresh airflow. After you have finished cooking, let the blower run for a few minutes to clear the air and help keep the kitchen fresh and clean. - Page 14 GREASE TRAY CLEANING THE GREASE TRAY Remove filter(s) by gently pulling up and out.The grease trays can DCS-IVH-48 easily be reached once the filters are removed. Grease collection trays are easily accessible at the center beneath the filter. See illustration below for location.
-
Page 15: Wiring Diagram
Wi ring Diagram DCS-IVH-48 & DCS-IVH-36 ISLAND VENT HOOD... -
Page 16: Warranty Information
Wa r ranty LENGTH OF WARRANTY One (1) Year Full parts and labor covers the entire product Five (5) Years Limited switches and motor DCS WILL COVER: All repair labor and parts found to be defective due to materials or workmanship for one full year from date of purchase. -
Page 17: Service
Se rvice HOW TO OBTAIN SERVICE: For warranty service, contact DCS Customer Service at (888) 281-5698. Before you call, please have the following information ready: • Model Number • Serial Number • Date of installation • A brief description of the problem Your satisfaction is of the utmost importance to us.
