Zodiac Plus Operator Manual
Figure 7-4 shows the dimensions of the Zodiac Plus LA (LH) printer.
236mm
204mm
71mm Printhead Stoke
107mm Printable Area
Figure 7-4: Zodiac Plus LA LH Printer Dimensions
7-10
Printer Dimensions
Rev AA
