Zodiac Plus Operator Manual
Figure 7-2 shows the dimensions of the Zodiac Plus (LH) printer.
180mm
204mm
71mm Printhead Stoke
53mm Printable Area
Figure 7-2: Zodiac Plus LH Printer Dimensions
7-8
Printer Dimensions
Rev AA
