Stopping the Printer

To stop the printer from printing, touch the red Stop button (Figure 3-
8). The printer returns to the OFFLINE state.
Figure 3-8: Stop Button

Understanding Printhead LEDs

Table 3-1 lists the printhead LEDs that indicate the status of the
printer.
Color
Amber
Green
Blue
Table 3-1: LED Indicators
Note: The amber LED also flashes when the printer is being powered on and
the printhead is initializing.
3-6 Stopping the Printer
Stop Button
On Flashing
Warning Signal Fault Signal
— Printhead is
printing
Power On —
Off
No warning or fault
—
No power to
printhead
