Overview of Printer Parts

The main parts of the Zodiac Plus printer is described as follows:
• CLARiTY Controller: Houses the power supply unit and touch
• Printer: Houses the printhead and ribbon. The data is transferred
9
8
1. CLARiTY Controller
2. Low Profile Cable Assembly
3. Sample Ribbon Roll
4. Air Regulator
5. 4 mm Air Tubing
6. Power Cable
7. CLARiTY Configuration Manager CD-ROM
8. Cassette
9. Printer
Figure 2-1:Printer Configuration Parts
Rev AA
screen. You can access jobs, setup jobs, set the various print
parameters using the touch screen
to the printhead from the CLARiTY controller. The printhead
prints onto the packaging film
Zodiac Plus Operator Manual
7
6
Overview of Printer Parts
1
2
3
4
5
2-3
