If the LED continues to flash green or the LED remains a solid red, the
connection to the battery may have come loose. To check the connection,
unplug the unit and then remove the two screws and battery cover, then
gently partially pull out the battery to inspect the battery wiring harness. Do
not tug or yank the battery or wiring harness. Pulling too hard may damage
the wiring harness or connection to the battery. Once the harness is
exposed, inspect the connectors and try re-seating the two connectors
together. Then re-install the wire harness and battery into the enclosure the
same way it was before removing. Then reinstall the cover and screws. Do
not over tighten the screws. Plug the unit back in. If the LED still remains
flashing green or solid red, unplug the unit and contact Soundcast Systems
customer service for further instructions.
To maximize performance of the system, it should always be fully charged
prior to operating the unit. The battery must only be operated between
the temperatures of -20ºC (-4ºF) and +50ºC (+122ºF). Operating the
battery outside of the specified temperature ranges will shorten
battery life and may result in permanent damage.
Playing Music on the Outcast Junior
Outcast Junior will play music from two different input sources.
1. Wireless playback from a Soundcast transmitter.
2. Wired playback from the auxiliary input connector located on the Outcast Junior.
Wireless playback from a Soundcast Transmitter
To setup a transmitter, refer to manual supplied with the Soundcast transmitter.
Note that each Soundcast transmitter will have a channel selector switch (channel 1, 2 or 3). You
will need to set Outcast Junior's channel selector switch to the same channel as the transmitter.
The Outcast Junior channel selector is located under the rubber cover located on the top left side
of the unit. The rubber cover is labeled "Aux in" and "Channel 1 2 3". Open the cover by grabbing
the small tab on the bottom of the cover. Gently pull upward, not outward. The cover is secured to the
unit so take care not to pull the cover off of the unit. Once the cover is in the up position, select
the proper channel switch setting to match the transmitter.
Rubber cover tab
Channel select switch
6
Battery Connector
r
