INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER

A050000APB
Door ajar warning light*
Tailgate open warning light*
Door and tailgate open position
indicator*
Seat belt warning light
High beam indicator
Low beam indicator
Turn signal indicator
Front fog light indicator*
Rear fog light indicator*
ESP indicator*
❈ For more detailed explanations, refer to section 4, "Instrument cluster".
* : if equipped
1 6
ESP OFF indicator*
ABS warning light*
Parking brake & Brake fluid
warning light
Engine oil pressure warning
light
Charging system warning light
Malfunction indicator*
Air bag warning light*
Immobilizer indicator*
Low fuel level warning light
Glow indicator (Diesel only)
Fuel filter warning light
(Diesel only)
Electric power steering (EPS)
system warning light*
TPMS (Tire Pressure Monitoring
System) malfunction indicator*
Low tire pressure telltale*
Low tire pressure position tell-
tale*
O/D
O/D OFF indicator*
OFF
