Morello Forni
ovens manufacturers in Genoa since 1969
FIRE BRICKS GAS OVENS RANGE "PG" WITH SINGLE GAS BURNER,
THERMOSTATIC DIGITAL CONTROLS
INSTRUCTIONS FOR THE INSTALLATION FOR THE USE
FOR THE MAINTENANCE
Builder:
Morello Forni S.a.s.
Office:
Via B. Parodi 35, 16014 Ceranesi (GE) Italy
Phone:
++39. 010 7401194
Fax:
++39.0107492194
e-mail:
info@morelloforni.com
Assistance : Contact either your retailer or the builder directly.
The builder claims the right to change in any moment without notice
the content of this Instructions Manual.
1
RANGE PG
MORELLO FORNI S. A. S.
