Morello Forni Evento FRV 100 Installation And Maintenance Instructions Manual

Ventilated turning bedplate electric oven
Hide thumbs Also See for Evento FRV 100:
Table of Contents

Advertisement

Quick Links

Morello Forni
ovens manufacturers in Genoa since 1969
Evento
RANGE
FRV 100
FRV 125
"
" "
"
VENtilAtEd tuRNiNG bEdplAtE ElEctRic oVEN
INSTALLATION AND MAINTENANCE INSTRUCTIONS.
rev.12 - 21
Manufacturer:
Morello Forni Italia S.r.l.
Address:
Via B. Parodi 35, 16014 Ceranesi (GE) Italia
Telephone:
++39. 010 7401194
Fax:
++39. 010 7492194
e-mail:
info@morelloforni.com
Technical Assistance: contact your local dealer or the manufacturer.
The manufacturer reserves the right to change, at any time and without prior notice,
the contents of this instruction manual.
1
FRV RANGE
MORELLO FORNI ITALIA S.R.L.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evento FRV 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Morello Forni Evento FRV 100

Summary of Contents for Morello Forni Evento FRV 100

  • Page 1 FRV 125 “ ” “ ” VENtilAtEd tuRNiNG bEdplAtE ElEctRic oVEN INSTALLATION AND MAINTENANCE INSTRUCTIONS. rev.12 - 21 Manufacturer: Morello Forni Italia S.r.l. Address: Via B. Parodi 35, 16014 Ceranesi (GE) Italia Telephone: ++39. 010 7401194 Fax: ++39. 010 7492194 e-mail: info@morelloforni.com...

  • Page 2: Declaration Of Conformity

    Forno rotante elettrico ventilato - Rotary electric ventilated oven Marchio commerciale - Trademark Morello Forni Modello - Type of designation Costruttore - Manufacturer Morello Forni S.a.s. di Morello Marco & C. Indirizzo - Address Via Bartolomeo Parodi 35 - 16014 Genova - ITALY Telefono - Telephone (+39).010.7401194 Telefax - Telefax (+39).010.7492194...

  • Page 3: Table Of Contents

    FRV 125 Wiring diagram ..............(*) LEGAL DISCLAIMER : MORELLO FORNI ITALY S.r.l. reserves the right to modify oven technical data and specs at any time, and without prior notice. Said data and specifications are purely indicative and in no way binding FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 4: Chapter. 1 General Contents

    1.3 cuStoMER’S dutiES The customer shall be responsible for the following: - Correct and safe installation of the oven received - Power supply - Connection to the flue - Consumables for cleaning - Ordinary maintenance FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 5: Oven Description

    All technical problems or servicing requests should be addressed to the supplier of the oven. 1.7 oRdERiNG SpARE pARtS All spare parts can be ordered from the supplier of the oven, who has a list of spare parts. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 6: Chapter. 2 Instructions For Installers

    . m o r e l l o f o r n i . c o m Mod./ Ref. peso/weight (kg) FRV100 1550 FRV125 FiG.2 Mod./ Ref. peso/weight (kg) FRV100 1850 FRV125 Mod./ Ref. peso/weight (kg) FRV100 1900 FRV125 alcune nostre finiture some of our finishes FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 7: Receipt Of The Oven

    2.2 REcEipt oF tHE oVEN Upon receipt of an oven manufactured by “MORELLO FORNI”, it is necessary to carefully read this manual before performing any handling or installation operation. The oven has been designed with the utmost attention and must be handled very carefully by the carrier.

  • Page 8: General Recommendations

    The part underneath the motor and the control console must remain free of any type of obstruction and be accessible for ordinary maintenance operations (FIG. 9), avoiding any form of occlusion that may prevent the necessary air circulation, which is essential for the furnace to function properly. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 9: Recommendations For External Coating

    Non combustible materials combustible materials must be like natural stones, ceramic applied by leaving a minimum tiles, heat resistant or distance of at least 10 centimeters. flame-proof materials can be applied directly on the surface. FiG.5 FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 10: Chapter. 3 Installation

    3.3 WiRiNG diAGRAMS iNFoRMAtioN The wiring diagrams for FRV 100 and FRV 125 ovens are shown on the last two pages of this manual. WIRING DIAGRAMS ARE DESIGNED TO BE USED BY QUALIFIED TECHNICIANS DURING MAINTENANCE OPERATIONS. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 11: List Of Components ( Frv 100 )

    ....MF.11.053 3.5 tEcHNicAl AiR EXtRActioN RAtiNGS ( * ) EXHAuSt VoluME tAblE 2 FRV RANGE ModEl FRV 100 FRV 125 Air Volume 600 m3 h 700 m3 h FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 12: Discharge Of The Condensation Produced

    FiG.6 WARNiNG!! tHE MotoR AiR MANiFoldS (b and c in Fig.11) MuSt Not bE coNNEctEd to ANY tYpE oF cHiMNEY, tHEY MuSt REMAiN FREE! FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 13: Frv 125

    The FRV 125 STANDARD “ COLOSSEUM”, above, has a single manifold to discharge steam that might be produced during baking - its diameter is 10 cm. The installer must guarantee an average exhaust volume of 1000 m3/h. It is possible to place the oven under a hood. FiG.8 FiG.13 FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 14: Chapter. 4 Programming And Control System "Inteltouch - Mf10

    Dome temperature indicator (12) Decrease value command Dome burner command (13) Bedplate burner command ON-OFF Switch (14) Internal Ventilation adjustment command Bedplate counterclockwise rotation command (15) Light On-Off switch Cooking program # 3 command FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 15: Bedplate Rotation Controls Description

    NotE: pid - Automatic electric power management system The FRV range of electric ovens comes equipped with a heating power management software, to limit electric con- sumption as much as possible, and improve performances consequently. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 16: Heaters Commands Description

    • Bedplate Heater status: OFF • Dome Heater: Enabled • Dome Heater led: on • Dome Heater status: ON -------------------------------------- • Bedplate Heater: Disabled • Bedplate Heater led: off • Bedplate Heater status: OFF FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 17: Dome Or Bedplate Temperature Adjustment

    2. Once the desired dome tempe- rature is reached, stop touching. After 5 seconds from the last touch, the temperature indicator will stop blinking, storing the new baking temperature. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 18: Dome Or Bedplate Heaters' Electric Power Adjustment

    2. Once the desired power percen- tage is displayed, stop touching. After 5 seconds from the last touch, the “POT” indicator stops blinking and shows Temperature digits, storing the new power per- centage. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 19: Air Circulation Inside The Furnace Adjustment

    4.7 oVEN lAMp Ovens’ furnace Lighting System (optional) is controlled via Light On-Off switch (15) icon. One touch on it will switch on the light, and icon color will change from blue to white. FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 20: Cooking Programs

    0 to 20, which user can modify by pressing “+” (10) or “-” (12) icons ( let’s suppose a set value of 20 for this example’s sake). plEASE NotE: EVERY cooKiNG pRoGRAM cAN bE StoppEd ANd cANcElEd At ANY tiME bY pRESSiNG SAME pRoGRAM REcAll icoN FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 21: Cooking Program Use Example

    30 seconds, during which user can churn out first batch and put in a second one. User can STOP AND CANCEL program at any time by pressing same Program Icon ( “1” in this case ). FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 22: Appendix A. Maintenance Tasks

    WARNiNG! GRAb tHE coNtAiNER oNlY WitH GloVES oR tHERMAl pRotEctioN ! tHE StAiNlESS StEEl cYliNdER cAN bE Hot. MAKE SuRE to SlidE it iN FRoM itS opEN RiM, WHEN puttiNG it bAcK iN plAcE. FRV RANGE MORELLO FORNI ITALIA S.R.L.
  • Page 23 This allows all dirt to fall under the bedplate, from where it is collected into the external container. 3. Gently slide out the external container, as in- structed at page 1, and empty it. WARNiNG ! tHE coNtAiNER cAN bE Hot - FRV RANGE MORELLO FORNI ITALIA S.R.L.
  • Page 24 WARNiNG ! NEVER clEAN tHE toucH ScREEN oR tHE StAiNlESS StEEl SHElF WitH A SoAKEd oR EXcESSiVElY dAMp clotH. too MucH WAtER cAN dAMAGE tHE ScREEN FRV RANGE MORELLO FORNI ITALIA S.R.L.
  • Page 25 3. Lift the frame, then take out the filter for cleaning. REMoVE ANd clEAN tHE MEtAl FiltER, WitH coMpRESSEd AiR oR liQuid. iN tHE lAttER cASE, MAKE SuRE tHE FiltER iS coMplEtElY dRY bEFoRE MouNtiNG it bAcK. FRV RANGE MORELLO FORNI ITALIA S.R.L.
  • Page 26 - gently remove the filter, indicated by the yellow arrow, and clean it as gently as possible. Put it back and close the frame. FRV RANGE MORELLO FORNI ITALIA S.R.L.
  • Page 27 HAS bEEN REMoVEd, clEAN tHE duSt oR diRt oVER tHE MotoR bodY. oNcE doNE, RE-ASSEMblE tHE pRotEctioN pANEl, bY cARRYiNG out tHE AboVE StEpS FRoM 11 to 1 FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 28: Appendix B. Programmed Startup Instructions

    FRV control system starts the countdown to the power-on. Bedplate temperature digits show minutes remaining to the power up. WARNiNG : do Not SWitcH oVEN oFF AFtER SEttiNG pRoGRAMMEd StARtup ! FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 29: Wiring Diagrams

    FRV RANGE MORELLO FORNI ITALIA S.R.L.

  • Page 30: Frv 125 Wiring Diagram

    FRV RANGE MORELLO FORNI ITALIA S.R.L.
  • Page 31 MORELLO FORNI S.A.S Via B. Parodi 35 - 16014 Ceranesi (GE) ITALY Phone: +39.010.7401194, Fax : +39.010.7492194 E-mail : info@morelloforni.com Cambio fasi di alimentazione - Serie FRV Power phase lead switch - FRV Range Se non udite un segnale acustico di conferma dell’accensione, ed il...
  • Page 32 MORELLO FORNI S.A.S Via B. Parodi 35 - 16014 Ceranesi (GE) ITALY Phone: +39.010.7401194, Fax : +39.010.7492194 E-mail : info@morelloforni.com Cambio fasi di alimentazione - Serie FRV Power phase lead switch - FRV Range 6. Ricollegare il secondo condutto- re estratto al posto del primo ( g.
