VENtilAtEd tuRNiNG bEdplAtE ElEctRic oVEN
INSTALLATION AND MAINTENANCE INSTRUCTIONS..
Manufacturer:
Address:
Telephone:
Fax:
e-mail:
Technical Assistance:
manufacturer reserves the right to change, at any time and without prior notice,
RANGE FRV100
Morello Forni
ovens manufacturers in Genoa since 1969
Evento
RANGE
Via B. Parodi 35, 16014 Ceranesi (GE) Italia
contact your local dealer or the manufacturer. The
the contents of this instruction manual.
"FRV 100"
Morello Forni S.a.s.
++39. 010 7401194
++39. 010 7492194
info@morelloforni.com
1
MORELLO FORNI S. A. S.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evento FRV 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Morello Forni Evento FRV 100

Summary of Contents for Morello Forni Evento FRV 100

  • Page 1 ++39. 010 7492194 e-mail: info@morelloforni.com Technical Assistance: contact your local dealer or the manufacturer. The manufacturer reserves the right to change, at any time and without prior notice, the contents of this instruction manual. RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 2: Dichiarazione Di Conformita

    Marchio commerciale - Trademark Morello Forni Modello - Type of designation FRV 100 Costruttore - Manufacturer Morello Forni S.a.s. di Morello Marco & C. Indirizzo - Address Via Bartolomeo Parodi 35 - 16014 Genova - ITALY Telefono - Telephone (+39).010.7401194 Telefax - Telefax (+39).010.7492194...
  • Page 3 Pag.13 4.2 Heaters commands description Pag.15 4.3 Temperature selection Pag.15 4.4 Adjustment of the air inside the furnace Pag.16 4.5 Oven lamp Pag.16 4.6 Working programme Pag.17 4.7 Setting a programme example Pag.18 RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 4: Chapter 1. General Contents

    1.3 cuStoMER’S dutiES The customer shall be responsible for the following: - Correct and safe installation of the oven received - Power supply - Connection to the flue - Consumables for cleaning - Ordinary maintenance RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 5: Oven Description

    All technical problems or servicing requests should be addressed to the supplier of the oven. 1.7 oRdERiNG SpARE pARtS All spare parts can be ordered from the supplier of the oven who has a list of spare parts. RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 6: Chapter 2. Instructions For Installers

    The section below shows a layout of the unit with the installation heights and dimensions in centimeters (FIG.2) . FiG.2 Internal diameter: 100 cm. Internal High: 18 cm. Door Dimension: 50 x 18 cm Total Wheight: 650 Kg Sizes in cm RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 7 Internal diameter: 100 cm. Internal High: 18 cm. Door Dimension: 50 x 18 cm Total Wheight: 650 Kg Sizes in cm RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 8 2.2 REcEipt oF tHE oVEN Upon receipt of an oven manufactured by “MORELLO FORNI”, it is necessary to carefully read this manual before performing any handling or installation operation. The oven has been designed with the utmost attention and must be handled very carefully by the carrier. All handling operations must be performed with efficient and appropriate unloading and installation equipment.

  • Page 9: General Recommendations

    The part underneath the motor and the control console must remain free of any type of obstruction and be accessible for ordinary maintenance operations, avoiding any form of occlusion that may prevent the ne- cessary air circulation, which is essential for the furnace to function properly. RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 10 10 centimeters. be applied directly on the surface. FiG.10 RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 11: Chapter. 3 Installation

    EP - Flame ignition/detection electrodes for the bedplate burner flame F1 - 3.15 A fuse F2 - 3.15 A fuse F3 - 1 A fuse F4 - 250 mA fuse F5 - 250 mA fuse RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 12 Make sure that the manifolds B and C are always free of any obstruction, to ensure the necessary air circulation, essential for the furnace to function properly. FiG.6 WARNiNG!! tHE MotoR AiR MANiFoldS (b and c in Fig.6) MuSt Not bE coNNEctEd to ANY tYpE oF cHiMNEY, tHEY MuSt REMAiN FREE! RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 13: Oven Start Up

    One touch on icon (6) “On/Off” activates dome and bedplate temperature releaver and relating status for thermostatic intervention system. Start button shows own running status changing Color from red to green and V/V. RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 14: Rotation Speed

    Active ongoing speed is marked by one Scale made by a series of queued lights Which lightening following action releaved On buttons (+)/(-) from minimum to maximum. After 5 seconds without any action releaved Selected speed becomes rekorded. RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 15: Temperature Selection

    Flashing icon (4) Dome Temp. monitor or (11) Bedplate temp. monitor showing active Change status for captioned value. By selected temperature for dome or bedplate, Relating heater, when enable to run, can Switch on to heat proper area. RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 16 Ovens equipped by light system, display on screen Icon relating button (15) “light button”. Switch on happens pressing said icon which shows Own action by color change from blue to white when light switch off becomes on. RANGE FRV100 MORELLO FORNI S. A. S.

  • Page 17: Use Example

    Thereafter screen output a series of six sounds To alert user about baking end-time for fi rst Batch-in pro- duct. User alerted can churn-out First pizzas and follows by others within an Averaged end abt. 30 secs. RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 18 User can record other two baking programs and rotation speeds onto buttons (2) and (3) which can be also settled selecting max time (999) for recorded rotation speeds to recall by correspondant icon. RANGE FRV100 MORELLO FORNI S. A. S.
  • Page 19 RANGE FRV100 MORELLO FORNI S. A. S.
