Summary of Contents for Icidu NI-707537
- Page 1 N A N O B R O A D B A N D R O U T E R WIREL E S S 15 0 N 1 5 0 MBP S M A N U A L N I - 7 0 7 5 3 7...
- Page 2 E N g L I S h C O N T E N T S O f T h E PA C k A g E T E C h N I C A L S P E C I f I C AT I O N S R A N g E O f A P P L I C AT I O N S h A R D W A R E I N S TA L L AT I O N R O U T E R C O N f I g U R AT I O N...
- Page 3 N A N O B R O A D B A N D R O U T E R W I R E L E S S 1 5 0 N 1 5 0 M B P S Thank you for buying this 150N router. If you want to interconnect several PC’s for shared Internet access, you will need an additional component to connect the PCs.
- Page 4 E N g L I S h C O N T E N T S O f T h E PA C k A g E Before starting the installation first check that all necessary parts are present. The box should contain: Wireless router 150N Power Adapter 5V CD with manual...
- Page 5 h A R D W A R E I N S TA L L AT I O N As soon as you have connected the router to the power adapter, the power LED (Green) will light up and the WLAN LED will flash. The other LEDs (Green) will light up as soon as one of the UTP port is connected to the computer.
- Page 6 R O U T E R C O N f I g U R AT I O N After you have correctly connected the router, you can start to configure it. for some providers you will need addition information, such as your user- name and a password.
- Page 7 Click on “Quick Setup” and then click on “Next”. Select your Internet connec- tion, and after your provider has given you a username and password, which is needed for cable connections, select the PPPoE option. If you already have an ADSL connection with an ADSL modem then select ‘Cable modem”.
- Page 8 If you have a PPPoE connection, enter your username in the “Account name” field and the password you were given by your provider in the “Password” field. Then click on “OK”. for changing the wireless settings, go to “wireless” and click “basic settings” If there is nothing you want to change, click on “Apply”.
- Page 9 After you have clicked on “Apply” you will return to the “Basic settings” screen. Now that the router has been set up it is important that the wireless function of the router is protected. If you do not protect the router then the people around you will be able to use your Internet connection.
- Page 10 Use this space to write down your router’s settings. Wireless Settings SSID : …………………………….. PSK Passphrase: …………………………….. To get the most out of your router, please see the complete manual on the CD-ROM.
- Page 11 W P S C O N f I g U R AT I O N WPS (Wi-fi Protected Setup) function allows you to add a new wireless device to an existing network quickly. WPS can only be used if the router also sup- ports this feature.
- Page 12 C E M A R k W A R N I N g This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. NATIONAL RESTRICTIONS This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without...
- Page 13 f C C S TAT E M E N T This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the fCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 14 Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. f C C R f R A D I AT I O N E x P O S U R E S TAT E M E N T: This device has been tested for compliance with fCC Rf Exposure (SAR) lim- its in the typical laptop computer configuration and this device can be used...
- Page 15 W A R R A N T y Unless specified otherwise, all items sold under the ICIDU name are covered by a 10-year warranty. No warranty or support is provided for the software and rechargeable batteries that are provided. Claims under warranty can be made only via the dealer from whom the item was purchased.
