TVonics DTR-Z500HD Quick Start Manual

DTR-Z500HD

Quick start guide

q

Package Contents

q
w
r
e
t
y
Digital TV recorder (DTR) Batteries (2xAAA)
q w
AC mains adaptor HDMI cable
r t
User guide Quick start guide
u i
Digital TV recorder
u
i
Remote control
e
RF cable
y
w

Inserting the Batteries into the Remote Control

• Always check the positive/negative symbols on the batteries to ensure they are inserted correctly.
• Don't forget to get rid of old batteries safely. Check with your local council for how you should get rid of
batteries. Never put batteries on a fire or in the bin with normal household waste.
e

Connecting Equipment to the Rear of the Recorder

q
DTR-Z500HD
Manufactured under license from
Dolby Laboratories. Dolby and the
double-D symbol are registered
trademarks of Dolby Laboratories.
w e
Plug your aerial lead into the RF IN socket of the recorder.
q
If required, plug the RF cable between the RF OUT socket of the recorder and your TV, Video or DVD
w
recorder.
Plug the HDMI cable between the HDMI OUT socket of the recorder and your TV.
e
Plug the supplied AC mains adaptor between the power socket of the recorder and a standard wall
r
socket. Only switch on the wall socket when all cables have been attached. (Do not cut off the
supplied AC mains adaptor's plug.)
Please refer to page 11 of the User Guide for information on connecting equipment using
a HDMI cable, a SCART cable, a USB Flash drive or an audio system using a SPDIF cable.
