Flexwatch FW3170 User Manual

Seyeon 1ch network video server user's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

FW3170 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4041-01
FW3170 User's Manual

(Product Guide)

Version 4.14(Rev.E)
April 13, 2012
1
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW3170 and is the answer not in the manual?

Questions and answers

Related Manuals for Flexwatch FW3170

Summary of Contents for Flexwatch FW3170

  • Page 1: Product Guide

    FW3170 User’s Manual FW3170 User’s Manual (Product Guide) Version 4.14(Rev.E) April 13, 2012 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 Revised: April 13, 2011 About This Document This document is prepared for users of FW3170 supplied by Seyeon Tech Co., Ltd. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer.

  • Page 3: Table Of Contents

    FW3170 P ..............................8 ACKING HARDWARE DESCRIPTION ........................ 9 2.1. FW3170 F ..............................9 RONT 2.2. FW3170 R ..............................10 FW3170 INSTALLATION AND BASIC SETUP ................. 11 3.1..............................11 EFORE NSTALLATION 3.2............................11 ACTORY EFAULT ETTINGS 3.3. FW3170 ..............................11...

  • Page 4: Product Overview

    FlexWATCH® 3170 is 1ch network video server which transmits digital images captured by Analog CCD camera over IP network. It can transmit up to 30fps@D1 over the existing network. You can monitor video of FW3170 through web browser(ie. MS Internet Explorer), if FW3170 is connected to network. FW3170 supports video compression both Motion-JPEG and H.264 simultaneously so that user can choose appropriate video...

  • Page 5: Key Features

    FW3170 User’s Manual 1.2. Key Features Standalone device with a built-in web server 10M/100M Auto-Sensing Ethernet Configuring and controlling through Web browser Max 30/25 fps transmission rate at D1 resolution in NTSC/PAL Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 Supports Dual Streaming in MJPEG and H.264...

  • Page 6: Technical Specification Of Fw3170

    FW3170 User’s Manual 1.3. Technical Specification of FW3170 32bit Embedded CPU Flash 8Mbytes /SDRAM: 128Mbytes Hardware Linux version 2.6.18 operating system Battery backed up real-time clock Video MJPEG compression H.264 NTSC : 720x480, 704x480, 352x240, 160x112 Resolution PAL : 720x576, 704x576, 352x288, 160x144...
  • Page 7 CE : Class A RoHS Dimensions (HxWxD) and 85(W) x 110(D) x 39(H) (in mm) weight About 0.214kg without power supply * All specifications are subject to change without prior notice. Table 1 : FW3170 Specification M4041-01 Seyeon Tech Co., Ltd...

  • Page 8: Fw3170 Packing List

    FW3170 User’s Manual 1.4. FW3170 Packing List FW3170’s packing box includes the following items. FW3170 Power Supply Unit (Power Cable & SMPS DC12V 1A Adapter) CD (User’s Manual, IP Installer and etc) Table 2 : FW3170 Packing List Please check all the listed items are included in your package. For any missing items, please contact your local distributor.

  • Page 9: Hardware Description

    FW3170 User’s Manual 2. Hardware Description 2.1. FW3170 Front View Picture 2 : FW3170 Front View D E F Name Description Video In BNC cable port for 1ch Video input. Video Out 1ch Video Output port displaying on Analog Monitor.

  • Page 10: Fw3170 Rear View

    FW3170 User’s Manual 2.2. FW3170 Rear View Picture 3 : FW3170 Rear Panel Name Description Power input ports for DC 12V 1A [SMPS]. Power Ensure to use the original power supply unit from the package. This button can reset the factory default settings at the system. Especially when a user lost his/her admin-password, or when it got any uncertain faulty operation.

  • Page 11: Fw3170 Installation And Basic Setup

    For installation of FW3170, please follow the steps below. Place the CCTV cameras in place and connect power supplies. Connect the video output ports of analog CCTV cameras to the video-in ports of FW3170. Connect the FW3170 to the Internet cable through the LAN port.
