FW5072 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4065-00
FW5072 User's Manual

(Product Guide)

Version 4.14
April 13, 2012
１ １ １ １
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW5072 and is the answer not in the manual?

Questions and answers

Related Manuals for Flexwatch FW5072

Summary of Contents for Flexwatch FW5072

  • Page 1: Product Guide

    FW5072 User’s Manual FW5072 User’s Manual (Product Guide) Version 4.14 April 13, 2012 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 FW5072 User’s Manual FW5072 User’s Manual About This Document Copyright Notice Disclaimer Trademarks Technical Support ２ ２ ２ ２ M4065-00 Seyeon Tech Co., Ltd...

  • Page 3: Table Of Contents

    HARDWARE DESCRIPTION ........................ 9 2.1. FW5072 F ..............................9 RONT 2.2. FW5072 R ..............................10 ANEL 2.2.1. COM Port Description ............................11 FW5072 INSTALLATION AND BASIC SETUP ................. 12 3.1..............................12 EFORE NSTALLATION 3.2............................12 ACTORY EFAULT ETTINGS 3.3.

  • Page 4: Product Overview

    FlexWATCH(Network Video Server, Network Camera) over TCP/IP network. It can transmit up to 120fps@HD over the existing network. You can monitor video of FW5072 through web browser(ie. MS Internet Explorer), if FW5072 is connected to network. Saving & search is possible as well with HDD equipped.

  • Page 5: Key Features

    FW5072 User’s Manual 1.2. Key Features Standalone device built-in web server 10M/100M/1000M Auto-Sensing Ethernet Configuration and control device through Web browser Max 240 fps transmission speed on TCP/IP network Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 Support Dynamic IP network by IPCCTVDNS Server...

  • Page 6: Specification For Fw5072

    FW5072 User’s Manual 1.3. Specification for FW5072 32bit Embedded CPU Flash 8Mbytes /SDRAM: DDR2 128Mbytes Hardware Linux version 2.6.24.4 operating system Battery backed up real-time clock MJPEG Video compression MPEG-4 H.264 2 Step frame rate (Fast on event/Slow on continuous recording mode) Recording Supports Linux File system.
  • Page 7 Windows XP Pro or later Internet Explorer 6.x or later Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video System integration support stream, embedded scripting and access to serial port peripherals over HTTP/TCP User can be installed user program daemon for event notification or sending image.

  • Page 8: Fw5072 Packing List

    FW5072 User’s Manual 1.4. FW5072 Packing List FW5072’s packing box includes the following items FW5072 1 EA Power Supply Unit 1 EA (Power Cable & SMPS DC12V 5A Adapter) CD (User’s Manual, IP Installer and etc) 1 EA Table 2 : FW5072 Packing list Please check all the listed items are included in your package.

  • Page 9: Hardware Description

    2.1. FW5072 Front View Picture 2 : FW5072 Front panel PART DESCRIPTION It indicates the status of operation & shutdown of FW5072. STATUS LED Blue LED turns on during normal operation after FW5072 boots. It indicates the status of access to LAN physically.

  • Page 10: Fw5072 Rear Panel

    Used to switch on/off power Power Switch Do not turn off the power switch until format is completed since fatal problem happens if users turn off the switch during HDD format. Table 5 : FW5072 Rear panel view M4065-00 Seyeon Tech Co., Ltd...

  • Page 11: Com Port Description

    FW5072 User’s Manual 2.2.1. COM Port Description Below image illustrates PIN No. of COM Port to connect in case of setting devices using console, numbers are displayed in order from the left. For RS-232 connection, RXD& TXD& GND are used only in general, RXD and TXD should be crossed to communicate properly in case it connects with PC one by one.

  • Page 12: Fw5072 Installation And Basic Setup

    For installation of FW5072, please follow the steps below. Place the FW5072 in place. Connect the FW5072 to the Internet cable through the LAN port. Connect the power supply of FW5072. After that, you need to follow the steps below.
